Self Aligning Ball Bearings 2210 E-2RS1KTN9/C3

Self Aligning Ball Bearings 2210 E-2RS1KTN9/C3

The 2210 E-2RS1KTN9/C3 is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, designed for radial loads. Its compact size (50mm×90mm×23mm) makes it easy to fit in tight spaces while handling loads up to 5152 lbf.

The double-row design and sealed construction help it run smoothly at speeds up to 4800 RPM, even in dusty conditions. The nylon cage reduces noise and vibration, ideal for quieter operation.

With a C3 radial clearance, it accommodates slight misalignments, perfect for applications like conveyor systems or agricultural machinery. The bearing comes pre-lubricated and works in temperatures from -30°C to 110°C.

Weighing 0.57kg, it’s a sturdy choice for industrial use. Compliant with RoHS and REACH standards, it’s also interchangeable with SKF bearings for easy replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210 E-2RS1KTN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
  • Price（$） 117.59
Self Aligning Ball Bearings 2210 E-2RS1KTN9/C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 2210 E-2RS1KTN9/C3 Bearing for Precision Tasks?

2210 E-2RS1KTN9/C3 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.

Its sealed construction and nylon cage provide reliable performance in various conditions, reducing maintenance needs.

With a dynamic radial load of 5152 lbf, it handles demanding applications while maintaining smooth operation.

The C3 radial clearance allows for thermal expansion, making it suitable for a wide temperature range.

Application

Industrial Uses of 2210 E-2RS1KTN9/C3 Bearing
The 2210 E-2RS1KTN9/C3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, extending service life in dusty environments.

What Makes 2210 E-2RS1KTN9/C3 Bearing a Preferred Choice?
In agricultural machinery, 2210 E-2RS1KTN9/C3 Bearing handles radial loads efficiently, even in uneven terrain. Its nylon cage reduces friction, making it suitable for moderate-speed applications.

Perfect Fit for Automation: 2210 E-2RS1KTN9/C3 Bearing
This bearing works well in robotic arms, where smooth movement is essential. The C3 radial clearance allows for thermal expansion during continuous operation.

Medical vs Industrial: Where 2210 E-2RS1KTN9/C3 Bearing Excels
While not typically used in medical devices, 2210 E-2RS1KTN9/C3 Bearing shines in industrial mixers and pumps. The chrome steel construction ensures durability under heavy loads.

How Does 2210 E-2RS1KTN9/C3 Bearing Support High-Speed Operations?
In electric motors, 2210 E-2RS1KTN9/C3 Bearing maintains stability at speeds up to 4,800 rpm. The lubricated design reduces maintenance needs for long-term reliability.
