Self Aligning Ball Bearings 2208KJ

Brand: TFL Bearing Interchangeable: SKF 2208KJ 40 mm × 80 mm × 23 mm Metric Sealed
Part number: 2208KJ
Self Aligning Ball Bearings 2208KJ
In Stock
US$45.09 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia40 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia80 mm
Outer Dia Tolerance-0.013mm to 0
Width23 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring49 mm
Internal Diameter On Outer Ring69.8 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,478 lbf
Static Radial Load1,564 lbf
Temperature Range-30° to 110 °C
Max Speed5,600 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.5 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2208KJ is a self-aligning ball bearing with a 40mm tapered bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4478 lbf and operates smoothly at speeds up to 5600 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, reducing maintenance needs. The steel cage adds durability, making it a reliable choice for heavy-duty use.

This bearing works well in temperatures from -30°C to 110°C and comes pre-lubricated for easy installation. Ideal for machinery with misalignment issues, like conveyor systems or agricultural equipment.

Weighing 0.5kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for hassle-free replacements.

Features

How Does 2208KJ Bearing Reduce Friction?

2208KJ Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
Its sealed construction keeps lubrication intact, reducing friction and wear over time.
The taper bore design allows for easy installation and alignment, enhancing operational efficiency.
With a dynamic radial load capacity of 4478 lbf, it performs reliably in various applications.

Why Choose 2208KJ Bearing for Precision Tasks?

2208KJ Bearing’s chrome steel rings and balls provide consistent performance under radial loads.
The sealed design prevents contamination, ensuring long-term precision and reduced maintenance.
Its maximum speed of 5,600 rpm makes it suitable for high-precision machinery.
The taper bore simplifies alignment, improving accuracy in critical applications.

Engineered for Reliability: 2208KJ Bearing

2208KJ Bearing is built with durable chrome steel components, offering strong resistance to wear.
The double-row ball design enhances load capacity and stability in radial applications.
Sealed construction protects against dust and moisture, extending service life.
With a temperature range of -30° to 110°C, it performs reliably in varied conditions.

Steel vs Ceramic Bearings: Strengths of 2208KJ Bearing

2208KJ Bearing uses chrome steel for its rings and balls, balancing cost and performance.
The steel cage ensures durability and reliable operation under radial loads.
Its sealed design offers better contamination protection compared to open bearings.
With a static radial load of 1564 lbf, it handles moderate to heavy loads effectively.

Application

Industrial Uses of 2208KJ Bearing
2208KJ Bearing is commonly used in industrial machinery like conveyor systems and mixers, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, extending service life in dusty environments.

Where Is 2208KJ Bearing Used?
In automotive applications, 2208KJ Bearing fits well in wheel hubs and transmissions, thanks to its double-row construction handling radial loads efficiently. The taper bore ensures a secure fit on shafts, reducing slippage during operation.

Built for Heavy-Duty Use: 2208KJ Bearing
For automation equipment, 2208KJ Bearing’s steel cage and chrome steel balls provide reliable performance in robotic arms and assembly lines. Its lubricated design reduces friction, supporting smooth movement even at moderate speeds.

Medical vs Industrial: Where 2208KJ Bearing Excels
While 2208KJ Bearing isn’t typically used in medical devices, it shines in industrial settings like pumps and compressors. The radial load capacity and temperature tolerance make it suitable for continuous operation in varied conditions.

Perfect Fit for Automation: 2208KJ Bearing
In consumer appliances like washing machines, 2208KJ Bearing’s sealed construction prevents water ingress, ensuring quiet and long-lasting performance. The metric sizing aligns with European and Asian manufacturing standards.
