Self Aligning Ball Bearings 2208E-K 2RS

Brand: TFL Bearing Interchangeable: SKF 2208E-K 2RS 40 mm × 80 mm × 23 mm Metric Sealed
Part number: 2208E-K 2RS
Self Aligning Ball Bearings 2208E-K 2RS
In Stock
US$87.19 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia40 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia80 mm
Outer Dia Tolerance-0.013mm to 0
Width23 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring49 mm
Internal Diameter On Outer Ring69.8 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,478 lbf
Static Radial Load1,564 lbf
Temperature Range-30° to 110 °C
Max Speed5,600 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.5 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2208E-K 2RS is a self-aligning ball bearing with a 40mm tapered bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4478 lbf and runs smoothly at speeds up to 5600 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces noise. The bearing comes pre-lubricated and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.5kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe use.

Features

Why Choose 2208E-K 2RS Bearing for Precision Tasks?

2208E-K 2RS Bearing features a double-row design with chrome steel rings and balls, ensuring accurate radial load handling.
Its dynamic radial load capacity of 4478 lbf makes it suitable for high-precision applications.

The sealed construction and nylon cage reduce friction and protect against contaminants.
With a maximum speed of 5,600 rpm, it offers smooth and reliable operation.

2208E-K 2RS Bearing’s tapered bore design simplifies installation and improves alignment.
Its temperature range of -30° to 110 °C ensures performance in varied conditions.

Application

Industrial Uses of 2208E-K 2RS Bearing
2208E-K 2RS Bearing is commonly used in industrial machinery, especially in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The sealed design helps keep contaminants out, extending the bearing’s lifespan in dusty environments.

What Makes 2208E-K 2RS Bearing a Preferred Choice?
In automotive applications, 2208E-K 2RS Bearing is often found in wheel hubs and transmissions, where its double-row construction handles radial loads efficiently. The taper bore ensures a secure fit, reducing slippage during high-speed operation.

Perfect Fit for Automation: 2208E-K 2RS Bearing
For robotic arms and automated production lines, 2208E-K 2RS Bearing offers smooth movement and reliable performance. The nylon cage reduces friction, making it suitable for continuous operation in precision equipment.

Medical vs Industrial: Where 2208E-K 2RS Bearing Excels
In medical devices like MRI machines, 2208E-K 2RS Bearing provides quiet and stable rotation, essential for accurate imaging. Its chrome steel construction ensures durability, while the sealed design maintains hygiene in sensitive environments.

How Does 2208E-K 2RS Bearing Support High-Speed Operations?
In electric motors and pumps, 2208E-K 2RS Bearing handles high-speed rotations with ease, thanks to its balanced design and lubricated construction. The radial clearance rating (CN) ensures optimal performance under varying load conditions.
