Self Aligning Ball Bearings 2208E-K 2RS C/3

Self Aligning Ball Bearings 2208E-K 2RS C/3

The 2208E-K 2RS C/3 is a self-aligning ball bearing with a 40mm tapered bore and 80mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4478 lbf and operates smoothly at speeds up to 5600 RPM.

Its double-row design and sealed construction help it stay aligned in misaligned shafts, while the nylon cage reduces noise and vibration. The bearing comes pre-lubricated for easy installation and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like conveyor systems or agricultural machinery where shaft misalignment can occur.

Weighing 0.5kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2208E-K 2RS C/3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 49 mm
  • Internal Diameter On Outer Ring 69.8 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4478 lbf
  • Static Radial Load 1564 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 0.5 kg
  • Price（$） 87.19
Self Aligning Ball Bearings 2208E-K 2RS C/3 dimension drawing
Download DWG Download PDF

Features

How Does 2208E-K 2RS C/3 Bearing Ensure Smooth Operation?

2208E-K 2RS C/3 Bearing features a double-row design with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 4478 lbf ensures steady performance in various applications.

The sealed construction and nylon cage help maintain lubrication and reduce contamination.

With a maximum speed of 5,600 rpm, it balances efficiency and durability for long-term use.

Application

Industrial Uses of 2208E-K 2RS C/3 Bearing
2208E-K 2RS C/3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor shaft misalignments. The sealed design keeps contaminants out, ensuring reliable performance in dusty environments.

In automotive applications, 2208E-K 2RS C/3 Bearing fits well in gearboxes and wheel hubs, thanks to its double-row construction for handling radial loads. The nylon cage reduces noise, making it suitable for passenger vehicles.

For robotics, 2208E-K 2RS C/3 Bearing offers smooth movement in articulated joints, where precision and durability are key. Its tapered bore ensures a secure fit, preventing slippage during high-speed operations.

In household appliances like washing machines, 2208E-K 2RS C/3 Bearing provides long-lasting performance with minimal maintenance. The lubricated design helps it run quietly, even under constant use.
