Self Aligning Ball Bearings 2207 E-2RS1KTN9/C3

Brand: TFL Bearing Interchangeable: SKF 2207 E-2RS1KTN9/C3 35 mm × 72 mm × 23 mm Metric Sealed
Part number: 2207 E-2RS1KTN9/C3
Self Aligning Ball Bearings 2207 E-2RS1KTN9/C3
In Stock
US$89.91 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia35 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia72 mm
Outer Dia Tolerance-0.013mm to 0
Width23 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring42.7 mm
Internal Diameter On Outer Ring62.69 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,275 lbf
Static Radial Load1,350 lbf
Temperature Range-30° to 110 °C
Max Speed6,300 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceC3
Weight0.41 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2207 E-2RS1KTN9/C3 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, designed for radial loads. Its compact size (23mm width) and chrome steel construction make it durable for various applications.

This double-row bearing handles dynamic radial loads up to 4275 lbf and spins smoothly at 6300 RPM. The sealed design and nylon cage help keep dirt out and reduce friction.

Its self-aligning feature compensates for minor misalignments, making installation easier. Ideal for machinery where shaft deflection or mounting errors might occur.

Pre-lubricated and compliant with RoHS/REACH standards, it operates in temperatures from -30°C to 110°C. Weighing 0.41kg, it’s a reliable choice for industrial equipment or automotive systems.

Features

How Does 2207 E-2RS1KTN9/C3 Bearing Reduce Friction?

2207 E-2RS1KTN9/C3 Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, enhancing efficiency and reducing energy consumption.

With a dynamic radial load capacity of 4275 lbf, it handles demanding applications while maintaining performance.
The sealed design protects against contaminants, further reducing wear and extending service life.

Its C3 radial clearance allows for thermal expansion, ensuring reliable operation in varying temperatures.
The tapered bore design simplifies installation, providing a secure fit for consistent performance.

Application

Common Applications of 2207 E-2RS1KTN9/C3 Bearing
2207 E-2RS1KTN9/C3 Bearing is widely used in industrial machinery, especially in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, extending its lifespan in dusty environments.

In automotive applications, 2207 E-2RS1KTN9/C3 Bearing is ideal for wheel hubs and transmissions, thanks to its radial load capacity and tapered bore for secure fitting. The nylon cage reduces noise, making it suitable for passenger vehicles.

For automation equipment, 2207 E-2RS1KTN9/C3 Bearing ensures smooth operation in robotic arms and assembly lines. Its C3 radial clearance allows for thermal expansion, maintaining performance under varying temperatures.

In household appliances like washing machines, 2207 E-2RS1KTN9/C3 Bearing provides reliable support for rotating drums. The chrome steel construction resists wear, even with frequent use.
