Self Aligning Ball Bearings 2206 E-RS1TN9/C3

Self Aligning Ball Bearings 2206 E-RS1TN9/C3

The 2206 E-RS1TN9/C3 is a self-aligning ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3510 lbf and runs smoothly at speeds up to 7500 RPM.

Its sealed design keeps lubrication in and contaminants out, while the nylon cage reduces noise and wear. The double-row construction helps it handle misalignment in applications where shafts may not be perfectly straight.

This bearing is pre-lubricated and works in temperatures from -30°C to 110°C. Ideal for machinery like conveyor systems or agricultural equipment where alignment flexibility is needed.

Weighing 0.26kg, it’s a compact yet durable choice. Compliant with RoHS and REACH standards, and interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2206 E-RS1TN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 36.7 mm
  • Internal Diameter On Outer Ring 54.06 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 3510 lbf
  • Static Radial Load 1046 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7500 rpm
  • Weight 0.26 kg
Self Aligning Ball Bearings 2206 E-RS1TN9/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 2206 E-RS1TN9/C3 Bearing

2206 E-RS1TN9/C3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3510 lbf, ensuring reliable performance in various applications.

The double-row design and sealed construction help maintain smooth operation even in challenging conditions.
With a maximum speed of 7,500 rpm, it balances efficiency and durability for long-term use.

Nylon cage material reduces friction and noise, making it suitable for precision machinery.
The C3 radial clearance allows for better thermal expansion handling in different environments.

Application

Common Applications of 2206 E-RS1TN9/C3 Bearing
2206 E-RS1TN9/C3 Bearing works well in industrial settings, especially for machinery with slight misalignments like conveyor belts or fans. Its sealed design keeps out dust and debris, reducing maintenance needs.

In automotive applications, 2206 E-RS1TN9/C3 Bearing fits nicely in wheel hubs or transmission systems, handling radial loads smoothly. The double-row construction adds stability for longer service life.

For automation equipment, 2206 E-RS1TN9/C3 Bearing supports robotic arms and assembly lines with reliable performance. The nylon cage helps dampen vibrations, making operations quieter.

Around the house, you might find 2206 E-RS1TN9/C3 Bearing in washing machines or power tools, where its durability stands up to daily use. The lubricated design ensures it runs smoothly without frequent servicing.
