Self Aligning Ball Bearings 2205 K

Self Aligning Ball Bearings 2205 K

The 2205 K is a self-aligning ball bearing with a 25mm tapered bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3218 lbf and operates smoothly at speeds up to 9000 RPM.

Its double-row design and sealed construction help maintain alignment and keep dirt out, while the nylon cage reduces friction. The bearing is pre-lubricated for easy use and works in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a reliable alternative for replacements. Perfect for machinery where misalignment might occur, such as conveyor systems or agricultural equipment.

Weighing just 0.16kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2205 K
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 31 mm
  • Internal Diameter On Outer Ring 46.21 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 3218 lbf
  • Static Radial Load 900 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 9000 rpm
  • Weight 0.16 kg
  • Price（$） 34.78
Self Aligning Ball Bearings 2205 K dimension drawing
Download DWG Download PDF

Features

How Does 2205 K Bearing Reduce Friction?

2205 K Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
Its nylon cage minimises friction, contributing to quieter operation and longer service life.
The sealed construction keeps lubrication in place, reducing maintenance needs.
With a maximum speed of 9,000 rpm, it offers reliable performance in various applications.

Application

Common Applications of 2205 K Bearing
2205 K Bearing is widely used in industrial machinery, especially where misalignment compensation is needed, such as conveyor systems and textile equipment. Its double-row design helps manage radial loads efficiently while maintaining smooth operation.

In automotive applications, 2205 K Bearing fits well in gearboxes and wheel hubs, thanks to its tapered bore for secure mounting. The sealed design keeps contaminants out, extending service life in demanding conditions.

For automation systems, 2205 K Bearing works reliably in robotic arms and assembly lines, where consistent alignment is key. The nylon cage reduces friction, ensuring quiet performance even at higher speeds.

Around the home, 2205 K Bearing can be found in appliances like washing machines, where its durability handles frequent use. The lubricated construction means less maintenance, making it a hassle-free choice for everyday devices.
