Self Aligning Ball Bearings 2205 K 2RS

Brand: TFL Bearing Interchangeable: SKF 2205 K 2RS 25 mm × 52 mm × 18 mm Metric Sealed
Part number: 2205 K 2RS
Self Aligning Ball Bearings 2205 K 2RS
In Stock
US$34.78 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia25 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia52 mm
Outer Dia Tolerance-0.013mm to 0
Width18 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring31 mm
Internal Diameter On Outer Ring46.21 mm
Chamfer Dimension1 mm
Performance
Dynamic Radial Load3,218 lbf
Static Radial Load900 lbf
Temperature Range-30° to 110 °C
Max Speed9,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.16 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2205 K 2RS is a self-aligning ball bearing with a 25mm tapered bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3218 lbf and runs smoothly at speeds up to 9000 RPM.

Its double-row design and sealed construction help it stay aligned and protected from dust, while the nylon cage reduces noise. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a handy replacement option. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing just 0.16kg, it’s lightweight yet durable. Pre-lubricated and compliant with RoHS and REACH standards for reliable use.

Features

Engineered for Precision: 2205 K 2RS Bearing

2205 K 2RS Bearing features a double-row design, ensuring smooth radial load distribution for enhanced stability.
Its chrome steel rings and balls provide reliable performance under dynamic loads up to 3218 lbf.

The sealed construction and nylon cage help maintain lubrication, reducing wear in various conditions.
With a maximum speed of 9,000 rpm, it balances efficiency and durability in demanding applications.

2205 K 2RS Bearing operates within a temperature range of -30° to 110°C, suitable for diverse environments.
Its tapered bore design simplifies installation, saving time and effort during setup.

Application

Industrial Uses of 2205 K 2RS Bearing
The 2205 K 2RS Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. Its sealed design keeps contaminants out, ensuring long service life in dusty environments.

In automotive applications, 2205 K 2RS Bearing fits well in wheel hubs and suspension systems, thanks to its radial load capacity. The nylon cage reduces noise, making it suitable for passenger vehicles.

For robotics, 2205 K 2RS Bearing’s double-row construction provides stability in articulated joints. The chrome steel balls offer smooth movement, essential for precision tasks in automated systems.

Where Is 2205 K 2RS Bearing Used?
You’ll find 2205 K 2RS Bearing in household appliances like washing machines, where its sealed design prevents water damage. The taper bore ensures a secure fit, even under constant vibration.

In medical devices, 2205 K 2RS Bearing’s lubricated design ensures quiet operation for imaging equipment. Its temperature range makes it reliable in various clinical settings.

Built for Heavy-Duty Use: 2205 K 2RS Bearing
The 2205 K 2RS Bearing handles heavy loads in industrial fans, with its double-row design distributing weight evenly. The chrome steel rings resist wear, even in continuous operation.

For 3D printers, 2205 K 2RS Bearing’s self-aligning capability reduces friction in moving parts. This helps maintain print accuracy over long periods.

Light-Duty vs Heavy-Duty: Best Uses for 2205 K 2RS Bearing
In light-duty applications like office printers, 2205 K 2RS Bearing’s compact size and quiet operation are ideal. For heavier tasks like agricultural machinery, its robust construction stands up to tough conditions.

The bearing’s metric sizing makes it interchangeable with many European brands, simplifying replacements. Its nylon cage also resists corrosion, useful in humid environments.
