Self Aligning Ball Bearings 2205 E-2RS1TN9/W64

Brand: TFL Bearing Interchangeable: SKF 2205 E-2RS1TN9/W64 25 mm × 52 mm × 18 mm Metric Sealed
Part number: 2205 E-2RS1TN9/W64
Self Aligning Ball Bearings 2205 E-2RS1TN9/W64
In Stock
US$84.20 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia25 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia52 mm
Outer Dia Tolerance-0.013mm to 0
Width18 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring31 mm
Internal Diameter On Outer Ring46.21 mm
Chamfer Dimension1 mm
Performance
Dynamic Radial Load3,218 lbf
Static Radial Load900 lbf
Temperature Range-30° to 110 °C
Max Speed9,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.16 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2205 E-2RS1TN9/W64 is a self-aligning ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3218 lbf and operates smoothly at speeds up to 9000 RPM.

Its double-row design and sealed construction keep dirt out and lubrication in, extending its lifespan. The nylon cage reduces friction, making it run quietly even at high speeds.

This bearing works well in temperatures from -30°C to 110°C and is pre-lubricated for easy installation. Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing just 0.16kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH standards, it’s also interchangeable with SKF bearings for hassle-free replacements.

Features

Why Choose 2205 E-2RS1TN9/W64 Bearing for Precision Tasks?

2205 E-2RS1TN9/W64 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 3218 lbf makes it suitable for high-performance applications.

The sealed construction and nylon cage provide protection against contaminants while reducing noise.
This design ensures smooth operation and extends the bearing’s service life.

With a maximum speed of 9,000 rpm, 2205 E-2RS1TN9/W64 Bearing balances speed and durability.
Its temperature range of -30° to 110°C allows for reliable performance in various environments.

The pre-lubricated design minimises maintenance needs, saving time and effort.
2205 E-2RS1TN9/W64 Bearing is a practical choice for applications requiring precision and reliability.

Application

Industrial Uses of 2205 E-2RS1TN9/W64 Bearing
2205 E-2RS1TN9/W64 Bearing is commonly used in conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

Where Is 2205 E-2RS1TN9/W64 Bearing Used?
In automotive applications, 2205 E-2RS1TN9/W64 Bearing fits well in steering columns and suspension systems, thanks to its radial load capacity. The nylon cage reduces noise, making it ideal for passenger vehicles.

Perfect Fit for Automation: 2205 E-2RS1TN9/W64 Bearing
2205 E-2RS1TN9/W64 Bearing works smoothly in robotic arms and automated assembly lines, where precision and reliability are key. Its lubricated design ensures consistent performance even during prolonged use.

Medical vs Industrial: Where 2205 E-2RS1TN9/W64 Bearing Excels
In medical devices like MRI machines, 2205 E-2RS1TN9/W64 Bearing offers quiet operation and minimal maintenance. For industrial pumps, its chrome steel construction handles high radial loads with ease.

Light-Duty vs Heavy-Duty: Best Uses for 2205 E-2RS1TN9/W64 Bearing
2205 E-2RS1TN9/W64 Bearing is versatile enough for light-duty applications like office printers, as well as heavy-duty uses in agricultural machinery. The temperature range suits both indoor and outdoor environments.
