Self Aligning Ball Bearings 2201 E-2RS1TN9

Self Aligning Ball Bearings 2201 E-2RS1TN9

The 2201 E-2RS1TN9 is a self-aligning ball bearing with a 12mm bore and 32mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 1404 lbf and can spin at speeds up to 16,000 RPM.

Its double-row design and sealed construction keep dirt out and lubrication in, ensuring smooth operation. The nylon cage reduces friction and noise, making it quieter in use.

This bearing works well in temperatures from -30°C to 110°C and is pre-lubricated for easy installation. It’s a practical choice for applications like electric motors or conveyor systems where alignment might shift.

Weighing just 0.053kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for hassle-free replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2201 E-2RS1TN9
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 14 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 15.5 mm
  • Internal Diameter On Outer Ring 27.34 mm
  • Chamfer Dimension 0.6 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 1404 lbf
  • Static Radial Load 322 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 16000 rpm
  • Weight 0.053 kg
  • Price（$） 30.46
Self Aligning Ball Bearings 2201 E-2RS1TN9 dimension drawing
Download DWG Download PDF

Features

How Does 2201 E-2RS1TN9 Bearing Reduce Friction?

2201 E-2RS1TN9 Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.

The sealed construction and nylon cage minimise friction, allowing for quieter operation and reduced wear.

With a dynamic radial load capacity of 1404 lbf, it handles demanding applications efficiently.

Its maximum speed of 16,000 rpm makes it suitable for high-speed operations while maintaining reliability.

Application

Common Applications of 2201 E-2RS1TN9 Bearing
2201 E-2RS1TN9 Bearing is widely used in industrial machinery, especially in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.
In automotive applications, 2201 E-2RS1TN9 Bearing fits well in electric motors and gearboxes, providing smooth radial load support. Its nylon cage reduces noise, making it suitable for quieter vehicle operation.
For home appliances like washing machines, 2201 E-2RS1TN9 Bearing offers reliable performance with its lubricated design, reducing maintenance needs. The compact size fits neatly into tight spaces without compromising durability.

Where Is 2201 E-2RS1TN9 Bearing Used?
You’ll often find 2201 E-2RS1TN9 Bearing in small electric motors, where its double-row design handles radial loads efficiently. The chrome steel construction ensures it can withstand daily wear and tear.
In robotics, 2201 E-2RS1TN9 Bearing works well in joint mechanisms, thanks to its self-aligning capability. The sealed bearings also protect against dust and moisture in dynamic environments.

Built for Heavy-Duty Use: 2201 E-2RS1TN9 Bearing
2201 E-2RS1TN9 Bearing excels in agricultural equipment, where rough conditions demand robust performance. Its sealed and lubricated design minimises downtime for maintenance.
The bearing’s nylon cage makes it a good fit for food processing machinery, as it resists corrosion and doesn’t require frequent relubrication.

Automotive vs Industrial: Applications of 2201 E-2RS1TN9 Bearing
In cars, 2201 E-2RS1TN9 Bearing supports auxiliary systems like alternators, where quiet operation is key. The metric sizing ensures compatibility with most European and Asian models.
For factory equipment, this bearing handles misalignment in pulley systems, reducing stress on other components. Its dynamic load rating makes it suitable for continuous operation.
