Self Aligning Ball Bearings 2201 E-2RS1TN9/W64

Brand: TFL Bearing Interchangeable: SKF 2201 E-2RS1TN9/W64 12 mm × 32 mm × 14 mm Metric Sealed
Part number: 2201 E-2RS1TN9/W64
Self Aligning Ball Bearings 2201 E-2RS1TN9/W64
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia12 mm
Bore Dia Tolerance-0.008mm to 0
Outer Dia32 mm
Outer Dia Tolerance-0.011mm to 0
Width14 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring15.5 mm
Internal Diameter On Outer Ring27.34 mm
Chamfer Dimension0.6 mm
Performance
Dynamic Radial Load1,404 lbf
Static Radial Load322 lbf
Temperature Range-30° to 110 °C
Max Speed16,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.053 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2201 E-2RS1TN9/W64 is a self-aligning ball bearing with a 12mm bore and 32mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1404 lbf and operates smoothly at speeds up to 16,000 RPM.

Its double-row design and sealed construction keep dirt out while the nylon cage reduces friction. Pre-lubricated for easy use, it works in temperatures from -30°C to 110°C.

This model fits SKF equivalents, making replacements straightforward. Perfect for applications like conveyor systems or electric motors where slight misalignments may occur.

Weighing just 0.053kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH standards for safe handling.

Features

Why Choose 2201 E-2RS1TN9/W64 Bearing for Precision Tasks?

2201 E-2RS1TN9/W64 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 1404 lbf makes it suitable for applications requiring accuracy and durability.

The sealed construction and nylon cage reduce friction and protect against contaminants, enhancing performance.
With a maximum speed of 16,000 rpm, it delivers smooth operation in high-speed environments.

2201 E-2RS1TN9/W64 Bearing’s lubricated design minimises maintenance needs, saving time and effort.
Its compact size (12 mm×32 mm×14 mm) allows for easy integration into various machinery.

Application

Industrial Uses of 2201 E-2RS1TN9/W64 Bearing
2201 E-2RS1TN9/W64 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

What Makes 2201 E-2RS1TN9/W64 Bearing a Preferred Choice?
In automotive applications, 2201 E-2RS1TN9/W64 Bearing is ideal for electric motors and gearboxes, thanks to its radial load capacity. The nylon cage reduces friction, making it suitable for high-speed operations.

Perfect Fit for Automation: 2201 E-2RS1TN9/W64 Bearing
For robotic arms, 2201 E-2RS1TN9/W64 Bearing offers smooth movement and reliability. Its compact size and metric dimensions make it easy to integrate into various automated systems.

Medical vs Industrial: Where 2201 E-2RS1TN9/W64 Bearing Excels
In medical devices like lab equipment, 2201 E-2RS1TN9/W64 Bearing provides quiet and precise rotation. The chrome steel construction ensures durability in both medical and industrial settings.
