Self Aligning Ball Bearings 1322KJ

Brand: TFL Bearing Interchangeable: SKF 1322KJ 110 mm × 240 mm × 50 mm Metric Open
Part number: 1322KJ
Self Aligning Ball Bearings 1322KJ
In Stock
US$1,091.83 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia110 mm
Bore Dia Tolerance-0.02mm to 0
Outer Dia240 mm
Outer Dia Tolerance-0.03mm to 0
Width50 mm
Width Tolerance-0.2mm to 0
External Diameter On Inner Ring154.35 mm
Internal Diameter On Outer Ring202.9 mm
Chamfer Dimension3 mm
Performance
Dynamic Radial Load36,675 lbf
Static Radial Load16,200 lbf
Temperature Range-30° to 110 °C
Max Speed3,600 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight11.5 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1322KJ is a self-aligning ball bearing with a 110mm tapered bore and 240mm outer diameter, built to handle heavy radial loads. Made from chrome steel, it supports dynamic loads up to 36675 lbf and operates smoothly at speeds up to 3600 RPM.

Its double-row design and open seal allow for easy lubrication and maintenance, while the steel cage ensures durability. The bearing can withstand temperatures from -30°C to 110°C, making it versatile for various environments.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for industrial machinery or equipment where misalignment might occur, such as conveyor systems or agricultural gear.

Weighing 11.5kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe and practical choice for demanding applications.

Features

Performance Features of 1322KJ Bearing

1322KJ Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 36675 lbf, ensuring reliable performance in heavy-duty applications.

The double-row design enhances load distribution, reducing stress on individual components.
With a maximum speed of 3,600 rpm, it balances durability and efficiency in various conditions.

1322KJ Bearing’s taper bore design simplifies installation, saving time and effort.
The steel cage maintains ball alignment, minimising wear and extending service life.

Suitable for temperatures from -30° to 110°C, it performs well in diverse environments.
Its open seal type allows for easy lubrication, ensuring smooth operation over time.

Application

Industrial Uses of 1322KJ Bearing
1322KJ Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable radial load support in demanding environments.

In automotive applications, 1322KJ Bearing fits well in truck wheel hubs and transmissions, thanks to its tapered bore for secure mounting. Its chrome steel construction offers durability under continuous use.

For automation equipment, 1322KJ Bearing provides smooth operation in robotic arms and assembly lines. The open seal design allows for easy lubrication, extending service life in high-speed scenarios.

Where Is 1322KJ Bearing Used?
You’ll often find 1322KJ Bearing in agricultural machinery like harvesters, where its radial load capacity handles uneven forces. The steel cage adds strength while maintaining flexibility.

In construction equipment, 1322KJ Bearing supports crane swivels and excavator joints, withstanding harsh conditions. Its metric sizing ensures compatibility with European and Asian machinery standards.

Built for Heavy-Duty Use: 1322KJ Bearing
1322KJ Bearing excels in mining equipment, where its dynamic load rating handles intense vibrations. The lubricated design reduces friction, even in dusty environments.

For printing presses, 1322KJ Bearing ensures precise paper handling with minimal maintenance. Its temperature range suits both indoor and outdoor operations.

Automotive vs Aerospace: Applications of 1322KJ Bearing
In trucks, 1322KJ Bearing manages wheel loads, while in aerospace ground equipment, it supports landing gear testing rigs. The taper bore ensures stability in both settings.

Its steel construction works equally well in railway freight systems and wind turbine yaw mechanisms. The self-aligning feature adapts to varying operational stresses.
