Self Aligning Ball Bearings 1317KJ

Brand: TFL Bearing Interchangeable: SKF 1317KJ 85 mm × 180 mm × 41 mm Metric Open
Part number: 1317KJ
Self Aligning Ball Bearings 1317KJ
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia85 mm
Bore Dia Tolerance-0.02mm to 0
Outer Dia180 mm
Outer Dia Tolerance-0.025mm to 0
Width41 mm
Width Tolerance-0.2mm to 0
External Diameter On Inner Ring117.6 mm
Internal Diameter On Outer Ring152.8 mm
Chamfer Dimension3 mm
Performance
Dynamic Radial Load21,938 lbf
Static Radial Load8,550 lbf
Temperature Range-30° to 110 °C
Max Speed4,800 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight5 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1317KJ is a self-aligning ball bearing with an 85mm tapered bore and 180mm outer diameter, measuring 41mm in width. Made from durable chrome steel, it’s built to handle radial loads up to 21938 lbf.

Its double-row design allows for slight misalignment, making it forgiving in less-than-perfect setups. The open seal type ensures easy access for lubrication, extending its service life.

With a maximum speed of 4800 RPM, it’s suitable for moderate-speed applications. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

Ideal for industrial machinery or conveyor systems where alignment flexibility is needed. Weighing 5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Features

How Does 1317KJ Bearing Reduce Friction?

1317KJ Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
Its precision-engineered taper bore minimises misalignment, reducing friction and wear.
The steel cage maintains ball alignment, enhancing operational efficiency.
With a dynamic radial load capacity of 21938 lbf, it performs reliably in demanding conditions.
Lubrication is optimised for consistent performance across a temperature range of -30° to 110°C.

Application

Industrial Uses of 1317KJ Bearing
1317KJ Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. The double-row design provides added stability under radial loads, making it suitable for demanding environments.

In automotive applications, 1317KJ Bearing can be found in gearboxes and drivetrains, where its tapered bore ensures a secure fit. The chrome steel construction offers durability, even under continuous use.

For automation equipment, 1317KJ Bearing supports robotic arms and assembly lines, thanks to its smooth operation and high load capacity. The open seal design allows for easy lubrication, extending its service life.

In construction machinery, 1317KJ Bearing handles the uneven loads typical of cranes and excavators. Its robust steel cage and radial clearance tolerance make it a reliable choice for rough conditions.

Household appliances like washing machines also benefit from 1317KJ Bearing’s ability to absorb vibrations. The metric sizing ensures compatibility with a wide range of European-designed products.
