Self Aligning Ball Bearings 1310 ETN9

Brand: TFL Bearing Interchangeable: SKF 1310 ETN9 50 mm × 110 mm × 27 mm Metric Open
Part number: 1310 ETN9
Self Aligning Ball Bearings 1310 ETN9
In Stock
US$42.99 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia50 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia110 mm
Outer Dia Tolerance-0.015mm to 0
Width27 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring70.3 mm
Internal Diameter On Outer Ring92.6 mm
Chamfer Dimension2 mm
Performance
Dynamic Radial Load9,810 lbf
Static Radial Load3,150 lbf
Temperature Range-30° to 110 °C
Max Speed8,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Weight1.2 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1310 ETN9 is a self-aligning ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 9810 lbf and operates smoothly at speeds reaching 8000 RPM.

Its double-row design and open seal type make it versatile for various setups, while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for machinery where misalignment or radial loads are common, such as conveyor systems or agricultural equipment.

Weighing 1.2kg, it’s a robust yet manageable choice. Compliant with RoHS and REACH standards, it ensures safe and eco-friendly use.

Features

How Does 1310 ETN9 Bearing Reduce Friction?

1310 ETN9 Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, allowing for quieter operation and reduced energy consumption.

With a dynamic radial load capacity of 9810 lbf, it handles demanding applications effortlessly.
Its open design and lubrication ensure consistent performance even at high speeds up to 8,000 rpm.

The self-aligning capability of 1310 ETN9 Bearing compensates for minor misalignments, prolonging service life.
Its chrome steel construction resists wear, making it suitable for a wide temperature range from -30° to 110°C.

Application

Industrial Uses of 1310 ETN9 Bearing
1310 ETN9 Bearing is commonly used in conveyor systems, where its self-aligning feature helps accommodate shaft misalignment. The double-row design provides stable radial load support, making it suitable for continuous operation.

In automotive applications, 1310 ETN9 Bearing works well in gearboxes and drivetrains, handling moderate radial loads with ease. Its nylon cage reduces friction, contributing to smoother performance in vehicle components.

For automation equipment, 1310 ETN9 Bearing ensures reliable motion control in robotic arms and assembly lines. The open seal design allows for easy lubrication, extending its service life in high-use environments.

What Makes 1310 ETN9 Bearing a Preferred Choice?
1310 ETN9 Bearing’s chrome steel construction offers durability in industrial fans and blowers, where consistent performance is key. The metric sizing ensures compatibility with a wide range of machinery.

In household appliances like washing machines, 1310 ETN9 Bearing provides quiet and efficient operation. Its self-aligning capability helps reduce wear, even with minor installation errors.
