Self Aligning Ball Bearings 1307-TVH

Self Aligning Ball Bearings 1307-TVH

The 1307-TVH is a self-aligning ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5962 lbf and operates smoothly at speeds reaching 11000 RPM.

Its double-row design and open seal allow for easy alignment and maintenance, while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.51kg, it’s a robust yet manageable choice for industrial use. Compliant with RoHS and REACH standards for safety and environmental care.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1307-TVH
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 51.55 mm
  • Internal Diameter On Outer Ring 67.5 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5962 lbf
  • Static Radial Load 1912 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.51 kg
  • Price（$） 38.46
Self Aligning Ball Bearings 1307-TVH dimension drawing
Download DWG Download PDF

Features

How Does 1307-TVH Bearing Reduce Friction?

1307-TVH Bearing features a double-row ball design with chrome steel rings and balls, ensuring smooth radial load distribution.
The nylon cage helps maintain ball alignment, reducing friction and wear during operation.

With a dynamic radial load capacity of 5962 lbf, it handles demanding applications efficiently.
Its maximum speed of 11,000 rpm makes it suitable for high-speed machinery.

The open seal design allows for easy lubrication, enhancing performance and longevity.
1307-TVH Bearing operates reliably in temperatures ranging from -30° to 110°C.

The precise tolerances and chamfered edges ensure easy installation and reduced stress points.
This design makes 1307-TVH Bearing a practical choice for various industrial uses.

Application

Industrial Uses of 1307-TVH Bearing
1307-TVH Bearing is commonly used in industrial machinery, especially in conveyor systems and pumps, where its self-aligning feature helps compensate for minor misalignments. The double-row design provides added stability, making it suitable for heavy radial loads.

What Makes 1307-TVH Bearing a Preferred Choice?
In automotive applications, 1307-TVH Bearing is often found in wheel hubs and transmissions, thanks to its ability to handle both radial and axial forces. The chrome steel construction ensures durability even under high-speed conditions.

Perfect Fit for Automation: 1307-TVH Bearing
For robotic arms and automated production lines, 1307-TVH Bearing offers smooth operation with minimal maintenance. Its nylon cage reduces friction, making it ideal for precision movements in tight spaces.

Medical vs Industrial: Where 1307-TVH Bearing Excels
While 1307-TVH Bearing is reliable in industrial settings, it also performs well in medical devices like diagnostic equipment. The lubricated design ensures quiet operation, which is essential in sensitive environments.
