Self Aligning Ball Bearings 1301 EM

Self Aligning Ball Bearings 1301 EM

The 1301 EM is a self-aligning ball bearing with a 12mm bore and 37mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2106 lbf and operates smoothly at speeds up to 28,000 RPM.

Its double-row design allows for slight misalignment, reducing wear and tear. The brass cage enhances durability, while the open seal simplifies maintenance.

This bearing is pre-lubricated and performs well in temperatures from -30°C to 110°C. It’s interchangeable with SKF models, making replacements straightforward.

Weighing just 0.073kg, it’s a lightweight option for applications like conveyor systems or electric motors where alignment flexibility is needed. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1301 EM
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 37 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 20.2 mm
  • Internal Diameter On Outer Ring 29.5 mm
  • Chamfer Dimension 1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 2106 lbf
  • Static Radial Load 486 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 28000 rpm
  • Weight 0.073 kg
  • Price（$） 18.51
Self Aligning Ball Bearings 1301 EM dimension drawing
Download DWG Download PDF

Features

Performance Features of 1301 EM Bearing

1301 EM Bearing is crafted with chrome steel rings and balls, offering strong resistance to radial loads.
Its double-row construction enhances load distribution, ensuring stability in various applications.

The brass cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 28,000 rpm, it delivers efficient performance for high-speed needs.

1301 EM Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication, ensuring consistent performance over time.

Application

Common Applications of 1301 EM Bearing
1301 EM Bearing is widely used in industrial machinery, especially in applications where slight misalignment needs to be accommodated, such as conveyor systems and textile equipment. Its double-row design helps distribute loads evenly, ensuring smooth operation.

In automotive applications, 1301 EM Bearing can be found in components like steering columns and auxiliary drives, where its radial load capacity and self-aligning feature are beneficial. The brass cage adds durability, making it suitable for long-term use.

For automation and robotics, 1301 EM Bearing’s compact size and high-speed capability make it ideal for robotic arms and precision machinery. The chrome steel construction ensures reliability even in demanding environments.

In household appliances like washing machines, 1301 EM Bearing provides quiet and efficient performance. Its open design allows for easy lubrication, extending the bearing’s lifespan in everyday use.
