Self Aligning Ball Bearings 1226

Self Aligning Ball Bearings 1226

The 1226 is a self-aligning ball bearing with a 130mm bore and 230mm outer diameter, crafted from sturdy chrome steel. Its double-row design handles radial loads up to 28575 lbf and operates smoothly at speeds up to 3600 RPM.

The open seal type allows for easy lubrication, while the nylon cage reduces friction and noise. It performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for heavy-duty machinery where misalignment or radial loads are common.

Weighing 8.3kg, it’s built for durability in demanding environments. Compliant with RoHS and REACH standards for safe industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1226
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 230 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 46 mm
  • Width Tolerance -0.25mm to 0
  • External Diameter On Inner Ring 163 mm
  • Internal Diameter On Outer Ring 201.4 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 28575 lbf
  • Static Radial Load 13162 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3600 rpm
  • Weight 8.3 kg
  • Price（$） 1195.31
Self Aligning Ball Bearings 1226 dimension drawing
Download DWG Download PDF

Features

How Does 1226 Bearing Reduce Friction?

1226 Bearing features a double-row design with chrome steel balls, ensuring smooth radial load distribution.
Its nylon cage minimises friction, enhancing efficiency and reducing energy consumption.
The precision-engineered raceway design further lowers friction, promoting quiet operation.
With a dynamic radial load capacity of 28575 lbf, it delivers reliable performance in various applications.

Why Choose 1226 Bearing for Precision Tasks?

1226 Bearing’s cylindrical bore design ensures precise alignment, crucial for accuracy in radial load applications.
The chrome steel construction provides durability, while the nylon cage reduces vibration and noise.
Its radial clearance of CN allows for optimal performance under varying operational conditions.
With a maximum speed of 3,600 rpm, it balances precision and efficiency effortlessly.

Engineered for Reliability: 1226 Bearing

1226 Bearing is built with high-quality chrome steel rings and balls, offering excellent wear resistance.
The double-row construction enhances load capacity, making it suitable for heavy-duty applications.
Its open seal type allows for easy lubrication, ensuring consistent performance over time.
Operating within a temperature range of -30° to 110°C, it adapts well to diverse environments.

Application

Industrial Uses of 1226 Bearing
1226 Bearing is commonly used in heavy machinery like conveyors and mixers, where its self-aligning feature compensates for minor misalignments. The double-row design provides added stability, making it suitable for high radial load applications.

Where Is 1226 Bearing Used?
In automotive manufacturing, 1226 Bearing supports components such as wheel hubs and transmissions, ensuring smooth rotation under varying loads. Its metric sizing makes it a versatile choice for global vehicle designs.

Built for Heavy-Duty Use: 1226 Bearing
For industrial fans and blowers, 1226 Bearing’s chrome steel construction offers durability in high-temperature environments. The nylon cage reduces friction, enhancing efficiency in continuous operation.

Automotive vs Aerospace: Applications of 1226 Bearing
While 1226 Bearing excels in automotive systems like drivetrains, it’s also found in aerospace ground equipment, where reliability is key. Its open design allows for easy lubrication, extending service life.

Perfect Fit for Automation: 1226 Bearing
In robotic arms and automated assembly lines, 1226 Bearing’s self-aligning capability ensures precise movement. The lubricated design minimises maintenance, ideal for high-uptime environments.
