Self Aligning Ball Bearings 1224 KM/C3

Self Aligning Ball Bearings 1224 KM/C3

The 1224 KM/C3 is a self-aligning ball bearing with a 120mm tapered bore and 215mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 26775 lbf and operates smoothly at speeds up to 4000 RPM.

Its double-row design and brass cage offer durability, while the open seal allows for easy lubrication. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like conveyor systems or industrial fans where misalignment might occur.

Weighing 6.5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1224 KM/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 215 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 42 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 149 mm
  • Internal Diameter On Outer Ring 187.2 mm
  • Chamfer Dimension 2.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 26775 lbf
  • Static Radial Load 11925 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 6.5 kg
  • Price（$） 807.5
Self Aligning Ball Bearings 1224 KM/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 1224 KM/C3 Bearing

1224 KM/C3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 26775 lbf, ensuring reliable performance in heavy-duty applications.

The brass cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 4,000 rpm, it balances durability and efficiency for various industrial uses.

1224 KM/C3 Bearing operates smoothly in temperatures ranging from -30° to 110 °C.
Its open design allows for easy lubrication, ensuring consistent performance over time.

The double-row construction enhances load distribution, minimising wear and tear.
This makes 1224 KM/C3 Bearing a practical choice for machinery requiring precision and reliability.

Application

Industrial Uses of 1224 KM/C3 Bearing
The 1224 KM/C3 Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its self-aligning feature compensates for minor misalignments. Its double-row design ensures reliable performance under radial loads, making it a solid choice for demanding environments.

In automotive applications, 1224 KM/C3 Bearing fits well in gearboxes and drivetrains, handling high radial loads with ease. The brass cage adds durability, while the C3 clearance allows for thermal expansion in high-speed scenarios.

For automation equipment, 1224 KM/C3 Bearing supports robotic arms and assembly lines, where precision and longevity are key. The chrome steel construction ensures smooth operation even in continuous-use settings.

Where Is 1224 KM/C3 Bearing Used?
You’ll often find 1224 KM/C3 Bearing in wind turbines, where its ability to handle misalignment and heavy loads is crucial. The lubricated design also helps maintain performance in outdoor conditions.

In printing machinery, 1224 KM/C3 Bearing ensures smooth paper feed and roller movement. Its metric sizing and taper bore make it compatible with a variety of European-designed equipment.
