Self Aligning Ball Bearings 1224-KM C/3

Self Aligning Ball Bearings 1224-KM C/3

The 1224-KM C/3 is a self-aligning ball bearing with a 120mm tapered bore and 215mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 26775 lbf and operates smoothly at speeds up to 4000 RPM.

Its double-row design and brass cage provide stability and longevity, while the open seal allows for easy lubrication. The bearing works well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like conveyor systems or industrial fans where misalignment might occur.

Weighing 6.5kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1224-KM C/3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 215 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 42 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 149 mm
  • Internal Diameter On Outer Ring 187.2 mm
  • Chamfer Dimension 2.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 26775 lbf
  • Static Radial Load 11925 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4000 rpm
  • Weight 6.5 kg
  • Price（$） 1045.96
Self Aligning Ball Bearings 1224-KM C/3 dimension drawing
Download DWG Download PDF

Features

Why Choose 1224-KM C/3 Bearing for Precision Tasks?

1224-KM C/3 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load rating of 26775 lbf makes it suitable for heavy-duty applications.

The brass cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 4,000 rpm, it offers reliable performance in various conditions.

1224-KM C/3 Bearing operates smoothly in temperatures from -30° to 110°C.
Its tapered bore design ensures secure fitting and easy installation.

Application

Common Applications of 1224-KM C/3 Bearing
In industrial settings, 1224-KM C/3 Bearing is widely used in heavy machinery like conveyor systems and large fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance under significant radial loads.

Where Is 1224-KM C/3 Bearing Used?
You’ll often find 1224-KM C/3 Bearing in automotive applications, particularly in truck wheel hubs, where its tapered bore provides a secure fit. The brass cage adds durability, making it suitable for high-vibration environments.

Built for Heavy-Duty Use: 1224-KM C/3 Bearing
For automation equipment, 1224-KM C/3 Bearing handles the demands of robotic arms and assembly lines with ease. Its chrome steel construction ensures long service life even in continuous operation.

Light-Duty vs Heavy-Duty: Best Uses for 1224-KM C/3 Bearing
In consumer appliances like large washing machines, 1224-KM C/3 Bearing offers smooth operation and noise reduction. The lubricated design minimises maintenance, making it a practical choice for household devices.
