Self Aligning Ball Bearings 1208KJ

Brand: TFL Bearing Interchangeable: SKF 1208KJ 40 mm × 80 mm × 18 mm Metric Open
Part number: 1208KJ
Self Aligning Ball Bearings 1208KJ
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia40 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia80 mm
Outer Dia Tolerance-0.013mm to 0
Width18 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring53.85 mm
Internal Diameter On Outer Ring67.5 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,478 lbf
Static Radial Load1,564 lbf
Temperature Range-30° to 110 °C
Max Speed11,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight0.42 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1208KJ is a self-aligning ball bearing with a 40mm tapered bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4478 lbf and operates smoothly at speeds up to 11000 RPM.

Its double-row design helps compensate for misalignment, while the open seal allows for easy lubrication. The steel cage ensures durability under various conditions.

This bearing suits environments with slight shaft misalignment, such as conveyor systems or agricultural machinery. It performs reliably in temperatures from -30°C to 110°C.

Weighing 0.42kg, it’s a robust yet manageable choice for industrial applications. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for hassle-free replacements.

Features

Why Choose 1208KJ Bearing for Precision Tasks?

1208KJ Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4478 lbf makes it suitable for high-performance applications.

The tapered bore design of 1208KJ Bearing allows for easy and secure mounting, reducing installation time.
With a maximum speed of 11,000 rpm, it delivers smooth operation in demanding conditions.

1208KJ Bearing’s steel cage maintains ball alignment, enhancing durability and reducing maintenance needs.
Its open seal type ensures efficient lubrication, extending the bearing’s service life.

Operating within a temperature range of -30° to 110°C, 1208KJ Bearing performs reliably in various environments.
The radial clearance of CN provides optimal performance for precision tasks.

Application

Industrial Uses of 1208KJ Bearing
1208KJ Bearing is commonly used in industrial settings, especially in machinery that requires smooth radial load handling, like conveyor belts and pumps. Its double-row design helps accommodate minor misalignments, reducing wear over time.

In automotive applications, 1208KJ Bearing fits well in components such as wheel hubs and transmissions, where its tapered bore ensures a secure fit. The chrome steel construction provides durability under varying road conditions.

For automation systems, 1208KJ Bearing works efficiently in robotic arms and assembly lines, thanks to its ability to handle moderate speeds and loads. The open seal design allows for easy lubrication, extending its service life.

In household appliances like washing machines, 1208KJ Bearing offers reliable performance with minimal maintenance. Its metric sizing makes it compatible with a wide range of European and Asian models.
