Self Aligning Ball Bearings 1207 C3

Self Aligning Ball Bearings 1207 C3

The 1207 C3 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4275 lbf and operates smoothly at speeds up to 13,000 RPM.

Its double-row design and open seal allow for easy lubrication, while the nylon cage reduces friction for quieter performance. The bearing works in temperatures from -30°C to 110°C.

With a C3 radial clearance, it accommodates slight misalignments, making it versatile for various setups. Ideal for machinery like conveyors or fans where alignment flexibility is needed.

Weighing 0.32kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, especially as it’s interchangeable with SKF bearings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1207 C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 47 mm
  • Internal Diameter On Outer Ring 60.9 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.32 kg
  • Price（$） 28.15
Self Aligning Ball Bearings 1207 C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 1207 C3 Bearing

1207 C3 Bearing features a double-row design, offering excellent radial load capacity up to 4275 lbf.
Its chrome steel construction ensures durability and smooth operation in various applications.
The nylon cage reduces friction and noise, making it suitable for high-speed use.
With a maximum speed of 13,000 rpm, it balances performance and reliability.
The C3 radial clearance allows for thermal expansion, ensuring stable operation.

Application

Common Applications of 1207 C3 Bearing
In industrial settings, 1207 C3 Bearing is commonly used in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stable performance even under varying radial loads.

Where Is 1207 C3 Bearing Used?
You’ll often find 1207 C3 Bearing in automotive applications like electric motors and pumps, thanks to its ability to handle moderate radial loads. The nylon cage reduces friction, making it a quiet and efficient choice.

Ideal for Precision: 1207 C3 Bearing
For medical devices such as lab equipment, 1207 C3 Bearing offers reliable operation due to its chrome steel construction. The C3 radial clearance allows for thermal expansion, ensuring consistent performance.

Automotive vs Industrial: Applications of 1207 C3 Bearing
In automotive systems, 1207 C3 Bearing supports components like alternators, while in industrial machinery, it’s used in gearboxes. Its versatility makes it suitable for both high-speed and moderate-load scenarios.

Perfect Fit for Automation: 1207 C3 Bearing
1207 C3 Bearing works well in robotic arms and automated assembly lines, where its self-aligning capability reduces wear. The lubricated design ensures smooth operation over long periods.
