Self Aligning Ball Bearings 1207 C/3

Self Aligning Ball Bearings 1207 C/3

The 1207 C/3 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4275 lbf and can spin at speeds up to 13,000 RPM.

Its double-row design and open seal make it adaptable to slight misalignments, while the nylon cage reduces friction for smoother operation. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like conveyor systems or agricultural machinery where alignment flexibility is needed.

Weighing 0.32kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1207 C/3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 47 mm
  • Internal Diameter On Outer Ring 60.9 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.32 kg
  • Price（$） 18.9
Self Aligning Ball Bearings 1207 C/3 dimension drawing
Download DWG Download PDF

Features

Why Choose 1207 C/3 Bearing for Precision Tasks?

1207 C/3 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4275 lbf makes it suitable for high-performance applications.
The nylon cage maintains ball alignment, reducing friction and noise during operation.
With a maximum speed of 13,000 rpm, it offers both durability and smooth performance.

Application

Key Fields for 1207 C/3 Bearing
1207 C/3 Bearing is commonly used in industrial machinery, especially in applications where misalignment compensation is needed, such as conveyor systems and textile equipment. Its double-row design helps maintain smooth operation even under radial loads.

In automotive applications, 1207 C/3 Bearing fits well in components like steering columns and auxiliary drives, thanks to its ability to handle slight shaft deflections. The nylon cage reduces friction, making it suitable for moderate-speed operations.

For automation systems, 1207 C/3 Bearing works reliably in robotic arms and assembly line mechanisms. The open seal design allows for easy relubrication, extending its service life in continuous-use environments.

Where Is 1207 C/3 Bearing Used?
You’ll find 1207 C/3 Bearing in household appliances like washing machines, where its self-aligning feature accommodates minor shaft misalignments. The chrome steel construction ensures durability under everyday loads.

In medical devices, 1207 C/3 Bearing provides stable performance in diagnostic equipment, where precision and reliability are essential. The lubricated design helps maintain quiet operation in sensitive environments.
