One Way Bearing HFL0606-KF-R

One Way Bearing HFL0606-KF-R

The HFL0606-KF-R is a one-way needle bearing with a 6mm bore and 10mm outer diameter, crafted from sturdy steel for reliable performance. Its compact width of 6mm makes it suitable for tight spaces, while the knurled design ensures a secure press-fit installation.
This triple-row bearing handles speeds up to 23,000 RPM and offers a torque capacity of 0.5 Nm, ideal for high-speed applications. The open seal design allows for easy lubrication, and the plastic spring ensures smooth operation.
With a temperature range of -30°C to 110°C, it performs well in various environments. Compliant with RoHS standards, it’s a safe choice for many uses.
Weighing just 1g, it’s lightweight yet durable. Perfect for applications like small motors or machinery where one-way motion is needed. Interchangeable with INA bearings, it’s a versatile option for replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number HFL0606-KF-R
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 6 mm
  • Outer Dia 10 mm
  • Width 6 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Triple Row
  • Knurled Yes
  • Seal Type Open
  • Series HFL Series
  • Ring Material Steel
  • Cage Material Steel
  • Needle Material Steel
  • Spring Material Plastic
  • Max Speed 23000 rpm
  • Torque Capacity 0.5 Nm
  • Lubrication Lubricated
  • Shaft Mount Type Press Fit
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Weight 1 g

Features

How Does HFL0606-KF-R Bearing Achieve High-Speed Performance?
HFL0606-KF-R Bearing features a triple-row needle design, providing excellent torque capacity of 0.5 Nm.
Its steel construction ensures durability, even at high speeds up to 23,000 rpm.
The knurled surface enhances grip, making it ideal for press-fit applications.
With a temperature range of -30° to 110°C, it performs reliably in various conditions.
Why Choose HFL0606-KF-R Bearing for Precision Tasks?
HFL0606-KF-R Bearing’s needle roller design offers precise motion control in compact spaces.
The steel cage and needles ensure smooth operation, reducing friction and wear.
Its lightweight design at just 1 gram makes it suitable for delicate applications.
The open seal type allows for easy lubrication, maintaining performance over time.
Engineered for Reliability: HFL0606-KF-R Bearing
HFL0606-KF-R Bearing is built with high-quality steel, ensuring long-lasting performance.
The triple-row construction distributes loads evenly, enhancing durability.
Its press-fit shaft mount type simplifies installation, saving time and effort.
With RoHS compliance, it meets environmental standards while delivering consistent results.

Application

Common Applications of HFL0606-KF-R Bearing
HFL0606-KF-R Bearing is widely used in industrial automation, especially in conveyor systems where its one-way rotation feature prevents backdriving. The press-fit design ensures a secure mount, ideal for high-speed operations.
In automotive applications, HFL0606-KF-R Bearing fits well in small gearboxes and starter motors, thanks to its compact size and reliable torque capacity. The steel construction handles frequent starts and stops without wear.
For robotics, HFL0606-KF-R Bearing’s triple-row needle design provides smooth motion in robotic arms and joints. The open seal allows easy lubrication, extending service life in demanding environments.
Consumer electronics like printers benefit from HFL0606-KF-R Bearing’s precision and low weight. Its knurled surface improves grip, preventing slippage in high-RPM applications.
