Needle Roller Thrust Bearing Washers TWD1018

Needle Roller Thrust Bearing Washers TWD1018

The TWD1018 needle roller thrust bearing washers are small, with a 0.625″ bore and 1.125″ outer diameter, crafted from spring steel for durability. They handle moderate loads and work well in temperatures from -30°C to 110°C.
Their slim 0.126″ width makes them ideal for tight spaces, while the spring steel material ensures resilience under pressure. These washers are interchangeable with INA models, offering flexibility for replacements.
Perfect for applications like automotive transmissions or small machinery where space is limited. Weighing just 11g, they’re lightweight yet sturdy. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number TWD1018
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.625"
  • Bore Dia Tolerance 0.032mm to 0.212mm
  • Outer Dia 1.125"
  • Outer Dia Tolerance -0.370mm to -0.04mm
  • Width 0.126"
  • System of Measurement Inch
  • Roller Bearing Type Needle
  • Type Washers
  • Material Spring Steel
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Weight 11 g
Needle Roller Thrust Bearing Washers TWD1018 dimension drawing
Download DWG Download PDF

Features

How Is TWD1018 Bearing Engineered for Reliability?
TWD1018 Bearing is crafted from spring steel, offering excellent durability and resistance to wear.
Its precise dimensions ensure a snug fit, reducing vibration and enhancing performance.
The needle roller design allows TWD1018 Bearing to handle high thrust loads efficiently.
With a temperature range of -30° to 110 °C, it performs reliably in various conditions.
TWD1018 Bearing’s lightweight design at just 11 g makes it ideal for applications where weight matters.
Its compatibility with INA bearings provides flexibility in replacement options.

Application

Essential Roles of TWD1018 Bearing
TWD1018 Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high axial loads. The spring steel construction ensures durability in demanding environments.
In automotive applications, TWD1018 Bearing supports clutch assemblies and transmission systems, providing smooth operation under heavy thrust. Its inch sizing makes it a practical choice for North American vehicle models.
For automation equipment, TWD1018 Bearing’s compact design fits well in robotic arms and precision machinery. The consistent performance and easy maintenance make it a reliable component in high-speed operations.
Medical devices like surgical tools benefit from TWD1018 Bearing’s precise load handling and resistance to wear. Its compliance with RoHS standards ensures safety in sensitive environments.
Household appliances such as washing machines often use TWD1018 Bearing for its quiet and efficient performance. The lightweight design and durability make it ideal for daily use.
