Needle Roller Thrust Bearing Washers AS160200

Needle Roller Thrust Bearing Washers AS160200

The AS160200 needle roller thrust bearing washers feature a 160mm bore and 200mm outer diameter, crafted from resilient spring steel. With a slim 1mm width, they fit neatly into compact assemblies.
Designed for high-load applications, these washers handle significant thrust forces while maintaining smooth operation. They perform reliably in temperatures ranging from -30°C to 110°C.
Their durable construction ensures long service life, even in demanding conditions. These washers are interchangeable with INA models, offering flexibility for replacements.
Ideal for use in gearboxes, transmissions, or industrial machinery where space is limited but performance is crucial. Weighing just 89g, they’re lightweight yet sturdy. Compliant with RoHS standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number AS160200
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 160 mm
  • Bore Dia Tolerance 0.085mm to 0.485mm
  • Outer Dia 200 mm
  • Outer Dia Tolerance -0.820mm to -0.1mm
  • Width 1 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Type Washers
  • Material Spring Steel
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Weight 89 g
Needle Roller Thrust Bearing Washers AS160200 dimension drawing
Download DWG Download PDF

Features

Why Choose AS160200 Bearing for Precision Tasks?
AS160200 Bearing is crafted from high-quality spring steel, offering durability and precision in demanding applications.
Its needle roller design ensures efficient load distribution, enhancing performance under thrust loads.
The precise bore and outer diameter tolerances allow for accurate fitting, reducing operational issues.
With a temperature range of -30° to 110°C, AS160200 Bearing performs reliably in varied environments.
Its lightweight design at 89 grams makes it easy to handle without compromising strength.
Compliant with RoHS standards, it meets environmental and safety requirements.

Application

Industrial Uses of AS160200 Bearing
AS160200 Bearing is commonly used in heavy machinery, such as construction equipment and hydraulic pumps, where its needle roller design efficiently handles high axial loads. The spring steel material ensures durability even in demanding environments.
Where Is AS160200 Bearing Used?
You’ll often find AS160200 Bearing in automotive transmissions, where its thin profile and robust construction help manage thrust loads smoothly. It’s also a reliable choice for industrial gearboxes due to its precise tolerances.
Built for Heavy-Duty Use: AS160200 Bearing
AS160200 Bearing excels in applications like agricultural machinery, where its ability to withstand high loads and harsh conditions is essential. The metric sizing makes it easy to integrate into various European and Asian equipment designs.
Automotive vs Aerospace: Applications of AS160200 Bearing
In automotive systems, AS160200 Bearing supports clutch assemblies and gear shifts, while in aerospace, its lightweight yet sturdy design is ideal for auxiliary equipment. The spring steel construction ensures reliability across both sectors.
