Needle Roller And Cage Assemblies K32X46X32

Needle Roller And Cage Assemblies K32X46X32

The K32X46X32 is a needle roller and cage assembly with a 32mm bore and 46mm outer diameter, crafted from sturdy steel. It handles radial loads up to 14850 lbf and spins smoothly at speeds up to 12600 RPM.
Its single-row design with a steel cage ensures durability and efficient performance. The assembly works well in temperatures ranging from -30°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like gearboxes or automotive systems where space is limited but high load capacity is needed.
Weighing just 119g, it’s lightweight yet robust for its size. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K32X46X32
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 32 mm
  • Outer Dia 46 mm
  • Width 32 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 14850 lbf
  • Static Radial Load 18900 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 12600 rpm
  • Weight 119 g
Needle Roller And Cage Assemblies K32X46X32 dimension drawing
Download DWG Download PDF

Features

How Does K32X46X32 Bearing Handle High-Speed Applications?
K32X46X32 Bearing features a steel cage and needles, providing robust support for high-speed operations.
With a maximum speed of 12,600 rpm, it ensures smooth performance in demanding conditions.
The dynamic radial load capacity of 14,850 lbf makes it suitable for heavy-duty applications.
Its compact design and single-row construction offer reliability without compromising on space.
K32X46X32 Bearing operates efficiently within a temperature range of -30° to 110°C.
The steel construction ensures durability, reducing the need for frequent replacements.

Application

Industrial Uses of K32X46X32 Bearing
K32X46X32 Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The steel construction ensures durability in demanding environments like conveyor systems.
In automotive applications, K32X46X32 Bearing fits well in transmission systems, providing smooth rotation under heavy loads. Its compact size makes it ideal for space-constrained areas like differential assemblies.
For automation equipment, K32X46X32 Bearing supports precise movements in robotic arms and linear guides. The high-speed capability allows for reliable performance in repetitive tasks.
Medical devices benefit from K32X46X32 Bearing’s consistent operation in imaging equipment. The steel needles and cage offer long service life with minimal maintenance.
In household appliances, K32X46X32 Bearing ensures quiet operation in washing machine drums. Its metric dimensions make it easy to replace in European and Asian models.
