Needle Roller And Cage Assemblies K25X31X17

Needle Roller And Cage Assemblies K25X31X17

The K25X31X17 is a needle roller and cage assembly with a 25mm bore and 31mm outer diameter, crafted from sturdy steel. It handles radial loads up to 4410 lbf and spins smoothly at speeds up to 17500 RPM.
Its single-row design and steel cage ensure durability, while the compact 17mm width fits snugly in tight spaces. The assembly performs reliably in temperatures from -30°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like gearboxes or automotive systems where space and load capacity are key.
Weighing just 19g, it’s lightweight yet robust. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K25X31X17
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 25 mm
  • Outer Dia 31 mm
  • Width 17 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 4410 lbf
  • Static Radial Load 6412 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 17500 rpm
  • Weight 19 g
Needle Roller And Cage Assemblies K25X31X17 dimension drawing
Download DWG Download PDF

Features

How Does K25X31X17 Bearing Handle High-Speed Applications?
K25X31X17 Bearing features a steel cage and needles, ensuring durability and smooth operation at high speeds.
With a maximum speed of 17,500 rpm, it is well-suited for demanding industrial applications.
The dynamic radial load capacity of 4,410 lbf allows K25X31X17 Bearing to perform reliably under heavy loads.
Its compact design, with a width of just 17 mm, makes it ideal for space-constrained installations.
K25X31X17 Bearing operates efficiently within a temperature range of -30° to 110 °C.
The steel construction provides resistance to wear, extending the bearing’s service life.

Application

Common Applications of K25X31X17 Bearing
K25X31X17 Bearing is widely used in industrial gearboxes, where its compact design and high load capacity make it ideal for space-constrained applications. The steel construction ensures durability even in demanding environments.
In automotive transmissions, K25X31X17 Bearing provides smooth operation under high radial loads, enhancing performance and longevity. Its metric sizing allows for easy integration with various vehicle models.
For automation systems, K25X31X17 Bearing’s high-speed capability makes it suitable for robotic arms and precision machinery. The single-row design simplifies installation and maintenance.
In household appliances like washing machines, K25X31X17 Bearing offers reliable performance with minimal noise. Its lightweight design contributes to energy efficiency and quieter operation.
