Needle Roller And Cage Assemblies C364216

Needle Roller And Cage Assemblies C364216

The C364216 is a needle roller and cage assembly with a 2.25″ bore and 2.625″ outer diameter, built from sturdy steel. It handles radial loads up to 13500 lbf and spins smoothly at speeds up to 7900 RPM.
Its single-row design with a steel cage ensures durability and consistent performance. The assembly operates well in temperatures ranging from -30°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like gearboxes or automotive components where space is limited but high load capacity is needed.
Weighing just 110.1g, it’s lightweight yet robust for its size. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number C364216
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 2.25"
  • Outer Dia 2.625"
  • Width 1"
  • System of Measurement Inch
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series C Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 13500 lbf
  • Static Radial Load 25200 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 7900 rpm
  • Weight 110.1 g
Needle Roller And Cage Assemblies C364216 dimension drawing
Download DWG Download PDF

Features

Performance Features of C364216 Bearing
C364216 Bearing is built with a robust steel cage and needles, offering high load capacity for demanding applications.
Its dynamic radial load rating of 13,500 lbf ensures reliable performance under stress.
The single-row design provides stability, making it suitable for compact spaces.
With a maximum speed of 7,900 rpm, it balances efficiency and durability.
C364216 Bearing operates in temperatures from -30° to 110°C, adapting to various environments.
Its steel construction resists wear, extending service life and reducing maintenance needs.

Application

Key Fields for C364216 Bearing
C364216 Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The steel construction ensures durability in demanding environments like conveyor systems.
In automotive applications, C364216 Bearing fits well in transmission systems, providing smooth rotation under heavy stress. Its inch sizing makes it a convenient choice for American and British vehicle models.
For robotics, C364216 Bearing’s compact design suits articulated arms, offering precision in repetitive movements. The high-speed capability up to 7900 rpm makes it reliable for automated processes.
Around the home, C364216 Bearing can be found in power tools like drills, where its load capacity supports consistent performance. The temperature range also allows for use in various climates without issues.
