Metric Single Direction Thrust Ball Bearing 53411

Metric Single Direction Thrust Ball Bearing 53411

The 53411 is a single-direction thrust ball bearing with a 55mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It manages thrust loads up to 43875 lbf and operates smoothly at speeds up to 2400 RPM.
Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial presses or lifting equipment where high thrust loads are expected.
Weighing 3.08kg, it’s built to handle demanding conditions while meeting RoHS and REACH standards for safety.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 53411
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Thrust
  • Seal Type Open
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.02mm to 0
  • Outer Dia Shaft Washer 120 mm
  • Width 50.5 mm
  • Width Tolerance +0.02mm to -0.3mm
  • Inner Dia Housing Washer 57 mm
  • Chamfer Dimension 1.5 mm
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Thrust Load 43875 lbf
  • Static Thrust Load 90000 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 2400 rpm
  • Weight 3.08 kg
Metric Single Direction Thrust Ball Bearing 53411 dimension drawing
Download DWG Download PDF

Features

What Makes 53411 Bearing Suitable for High-Temperature Applications?

53411 Bearing is crafted from 52100 chrome steel, offering excellent resistance to high temperatures up to 110°C.
Its robust construction ensures stable performance even in demanding thermal conditions.

The stainless steel cage maintains ball alignment, reducing friction and heat generation.
This design helps 53411 Bearing operate smoothly under heavy thrust loads.

With a dynamic thrust load capacity of 43875 lbf, it handles intense pressure without compromising efficiency.
The open seal design allows for easy lubrication, further enhancing its high-temperature suitability.

Application

Industrial Uses of 53411 Bearing
53411 Bearing is commonly used in heavy machinery like hydraulic presses and large conveyor systems, where its high thrust load capacity handles intense axial forces. The chrome steel construction ensures durability even in demanding industrial environments.

Where Is 53411 Bearing Used?
You’ll often find 53411 Bearing in automotive applications such as heavy-duty truck transmissions, where its robust design manages significant thrust loads. Its metric sizing makes it a reliable fit for various European and Asian vehicle models.

Built for Heavy-Duty Use: 53411 Bearing
53411 Bearing excels in construction equipment like cranes and excavators, thanks to its ability to withstand high static and dynamic loads. The stainless steel cage adds extra resistance to wear, making it a long-lasting choice.

Medical vs Industrial: Where 53411 Bearing Excels
While 53411 Bearing isn’t typically used in medical devices, it shines in industrial settings like mining equipment, where its strength and reliability are crucial. The open design allows for easy lubrication, extending its service life.

Perfect Fit for Automation: 53411 Bearing
In automated production lines, 53411 Bearing supports heavy robotic arms and assembly systems, ensuring smooth operation under constant axial loads. Its temperature tolerance makes it suitable for varied working conditions.
