Metric Single Direction Thrust Ball Bearing 51101

Brand: TFL Bearing Interchangeable: SKF 51101 12 mm × 26 mm × 9 mm Metric Open
Part number: 51101
Metric Single Direction Thrust Ball Bearing 51101
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia12 mm
Bore Dia Tolerance-0.008mm to 0
Outer Dia26 mm
Outer Dia Tolerance-0.01mm to 0
Outer Dia Shaft Washer26 mm
Width9 mm
Width Tolerance+0.02mm to -0.25mm
Inner Dia Housing Washer13 mm
Chamfer Dimension0.3 mm
Performance
Dynamic Thrust Load2,340 lbf
Static Thrust Load3,735 lbf
Temperature Range-30° to 110 °C
Max Speed13,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionThrust
Seal TypeOpen
Weight0.022 kg
Material
Ring Material52100 Chrome Steel
Ball Material52100 Chrome Steel
Cage MaterialStainless Steel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 51101 is a compact single-direction thrust ball bearing, measuring 12mm in bore and 26mm in outer diameter, crafted from sturdy chrome steel. It supports thrust loads up to 2340 lbf and can spin at speeds up to 13000 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing operates efficiently in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for small machinery or devices where space is limited but thrust load handling is needed.

Weighing only 0.022kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s safe for various industrial applications.

Features

Why Choose 51101 Bearing for Precision Tasks?

51101 Bearing is crafted from 52100 chrome steel, offering a balance of strength and precision for thrust applications.
Its dynamic thrust load capacity of 2340 lbf ensures reliable performance in high-demand scenarios.
The stainless steel cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 13,000 rpm, it delivers smooth operation in precision tasks.

Application

Industrial Uses of 51101 Bearing
51101 Bearing is commonly used in machine tools, where its single-direction thrust capability handles axial loads efficiently. The open seal design simplifies lubrication, ideal for workshop environments.

What Makes 51101 Bearing a Preferred Choice?
In automotive applications like gearboxes, 51101 Bearing’s chrome steel construction ensures durability under constant thrust. Its compact size fits neatly into tight spaces without compromising performance.

Built for Heavy-Duty Use: 51101 Bearing
For conveyor systems, 51101 Bearing’s stainless steel cage resists wear from continuous operation. The metric dimensions make it easy to replace in European-designed machinery.

Medical vs Industrial: Where 51101 Bearing Excels
While suitable for industrial presses, 51101 Bearing also performs well in medical centrifuges due to its smooth rotation. The temperature range accommodates both sterile environments and factory floors.

Perfect Fit for Automation: 51101 Bearing
In robotic arms, 51101 Bearing provides precise movement with minimal maintenance. The 13,000 rpm rating supports high-speed operations without overheating.
