Mast Guide Bearings MG 306 DDL‑8

Mast Guide Bearings MG 306 DDL‑8

The MG 306 DDL‑8 is a mast guide bearing with a 30mm inner diameter and 75.9mm outer diameter, designed for stability in demanding applications. Its compact width of 24mm makes it suitable for tight spaces, while the 6mm radius ensures smooth operation.

With a dynamic capacity of 21,000 N and static capacity of 16,000 N, it handles heavy loads reliably. The bearing’s robust construction ensures durability even under continuous use.

Weighing just 0.567kg, it’s lightweight yet strong, ideal for industrial machinery or construction equipment. Its design allows for easy installation and maintenance, making it a practical choice for engineers and technicians.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number MG 306 DDL‑8
  • Brand TFL & OEM
  • Inner Diameter (d) 30.000 mm
  • Outer Diameter (D) 75.90 mm
  • Inner Ring Width (b) 23.5 mm
  • Outer Ring Width (B) 24.000 mm
  • Radius (R) 6 mm
  • Dynamic Capacity (Cr.) 21,000 N
  • Static Capacity (Cor.) 16,000 N
  • Weight 0.567 Kg
Mast Guide Bearings MG 306 DDL‑8 dimension drawing
Download DWG Download PDF

Features

Performance Features of MG 306 DDL‑8 Bearing

MG 306 DDL‑8 Bearing is built with precise dimensions of 30.000 mm x 75.90 mm x 24.000 mm, ensuring a perfect fit for mast guide applications.
Its dynamic capacity of 21,000 N allows it to handle significant loads with ease.

The bearing’s static capacity of 16,000 N ensures stability even under heavy pressure.
With a weight of 0.567 Kg, it offers a balance between strength and portability.

The 6 mm radius design reduces stress concentrations, enhancing durability.
MG 306 DDL‑8 Bearing is ideal for applications requiring reliable performance and long service life.

Application

Industrial Uses of MG 306 DDL‑8 Bearing
MG 306 DDL‑8 Bearing is commonly used in construction equipment, such as crane mast guides, where its robust design handles heavy loads with ease. The 30mm bore size ensures a secure fit for various shaft diameters.

Where Is MG 306 DDL‑8 Bearing Used?
You’ll find MG 306 DDL‑8 Bearing in agricultural machinery, supporting components like harvesters and tractors. Its dynamic capacity of 21,000 N makes it reliable for demanding outdoor conditions.

Built for Heavy-Duty Use: MG 306 DDL‑8 Bearing
MG 306 DDL‑8 Bearing excels in material handling systems, such as conveyor belts, thanks to its 75.90 mm outer diameter. The stainless steel construction ensures long-lasting performance even in dusty environments.

Automotive vs Aerospace: Applications of MG 306 DDL‑8 Bearing
In automotive steering systems, MG 306 DDL‑8 Bearing provides smooth rotation, while its precision suits aerospace landing gear mechanisms. The 24mm width offers stability in both applications.

Perfect Fit for Automation: MG 306 DDL‑8 Bearing
MG 306 DDL‑8 Bearing works well in robotic arms, where its 16,000 N static capacity ensures precision movement. The 6mm radius allows for easy integration into compact designs.
