Mast Guide Bearings MG 306 DDL‑7

Mast Guide Bearings MG 306 DDL‑7

The MG 306 DDL‑7 is a mast guide bearing with a 30mm inner diameter and 75.6mm outer diameter, designed for sturdy performance. Its compact width of 24mm makes it suitable for tight spaces, while the 6mm radius ensures smooth operation.

With a dynamic load capacity of 21,000 N and static load capacity of 16,000 N, it handles heavy loads with ease. The bearing’s durable construction ensures reliability in demanding conditions.

Weighing just 0.567kg, it’s lightweight yet robust, ideal for applications like construction equipment or industrial machinery. Its design allows for easy installation and maintenance, making it a practical choice for various settings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number MG 306 DDL‑7
  • Brand TFL & OEM
  • Inner Diameter (d) 30.000 mm
  • Outer Diameter (D) 75.60 mm
  • Inner Ring Width (b) 23.5 mm
  • Outer Ring Width (B) 24.000 mm
  • Radius (R) 6 mm
  • Dynamic Capacity (Cr.) 21,000 N
  • Static Capacity (Cor.) 16,000 N
  • Weight 0.567 Kg
Mast Guide Bearings MG 306 DDL‑7 dimension drawing
Download DWG Download PDF

Features

Performance Features of MG 306 DDL‑7 Bearing

MG 306 DDL‑7 Bearing is built with precise dimensions of 30.000 mm x 75.60 mm x 24.000 mm, ensuring a perfect fit for mast guide applications.
Its dynamic capacity of 21,000 N allows it to handle significant loads with ease.

The bearing’s static capacity of 16,000 N ensures stability even under heavy stress.
With a weight of 0.567 Kg, it offers a balance between strength and portability.

The 6 mm radius design enhances durability and reduces stress concentrations.
This makes MG 306 DDL‑7 Bearing suitable for demanding industrial environments.

Application

Industrial Uses of MG 306 DDL‑7 Bearing
MG 306 DDL‑7 Bearing is commonly used in construction equipment, such as mast guides for forklifts, where its robust design handles heavy loads with ease. The 30mm bore size makes it a versatile fit for various industrial applications.

Where Is MG 306 DDL‑7 Bearing Used?
In material handling systems, MG 306 DDL‑7 Bearing ensures smooth movement in guide rails and lifting mechanisms. Its dynamic capacity of 21,000 N makes it suitable for repetitive, high-stress operations.

Built for Heavy-Duty Use: MG 306 DDL‑7 Bearing
MG 306 DDL‑7 Bearing excels in agricultural machinery, particularly in harvesters and tractors, where durability is key. The 75.60 mm outer diameter provides stability under challenging field conditions.

Automotive vs Aerospace: Applications of MG 306 DDL‑7 Bearing
MG 306 DDL‑7 Bearing finds its place in automotive steering systems, offering reliable performance under axial loads. While not typically used in aerospace, its precision suits heavy machinery and industrial automation.

Essential Roles of MG 306 DDL‑7 Bearing
MG 306 DDL‑7 Bearing supports conveyor systems in warehouses, ensuring efficient material transport. Its static capacity of 16,000 N guarantees long-term reliability in continuous operation environments.
