Mast Guide Bearings MG 110mm‑3

Mast Guide Bearings MG 110mm‑3

The MG 110mm-3 mast guide bearing is a sturdy unit measuring 110mm in inner diameter and 253mm in outer diameter, with a width of 82.55mm. Built to handle heavy loads, it supports dynamic capacities up to 454,000 N and static loads of 712,000 N.

Its robust design includes chamfered edges for easier installation and alignment. The bearing’s durable construction ensures reliable performance in demanding conditions.

Weighing 27.2kg, it’s a solid choice for heavy-duty applications like construction equipment or industrial machinery. Its dimensions and load capacity make it suitable for guiding systems under high stress.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number MG 110mm‑3
  • Brand TFL & OEM
  • Inner Diameter (d) 110.000 mm
  • Outer Diameter (D) 253.00 mm
  • Inner Ring Width (b) 74.14 mm
  • Outer Ring Width (B) 82.550 mm
  • Radius (R) chamfer
  • Dynamic Capacity (Cr.) 454,000 N
  • Static Capacity (Cor.) 712,000 N
  • Weight 27.2155 Kg
Mast Guide Bearings MG 110mm‑3 dimension drawing
Download DWG Download PDF

Features

Performance Features of MG 110mm‑3 Bearing

MG 110mm‑3 Bearing is built to handle high dynamic loads, with a capacity of 454,000 N for demanding applications.
Its robust design ensures stability and reliability under heavy use.

The static capacity of 712,000 N makes MG 110mm‑3 Bearing suitable for applications requiring long-term durability.
Its dimensions (110.000 mm x 253.00 mm x 82.550 mm) provide a precise fit for specific machinery needs.

With a weight of 27.2155 Kg, MG 110mm‑3 Bearing is designed for heavy-duty performance.
The chamfered edges reduce stress concentrations, enhancing overall longevity.

Application

Industrial Uses of MG 110mm‑3 Bearing
MG 110mm‑3 Bearing is commonly used in heavy machinery, such as cranes and construction equipment, where its high dynamic capacity handles substantial loads with ease. The robust design ensures longevity even in demanding environments.

In wind turbines, MG 110mm‑3 Bearing plays a key role in supporting the mast, providing stability and reducing friction during rotation. Its large outer diameter and weight make it ideal for such large-scale applications.

For industrial automation, MG 110mm‑3 Bearing is often found in robotic arms and conveyor systems, where precision and durability are essential. The chamfered edges help with easy installation and maintenance.

Where Is MG 110mm‑3 Bearing Used?
MG 110mm‑3 Bearing is a reliable choice for marine applications, such as ship cranes, due to its corrosion-resistant materials and high static capacity. The weight and size make it suitable for heavy-duty maritime use.

In mining equipment, MG 110mm‑3 Bearing supports large loads and harsh conditions, ensuring smooth operation of drills and excavators. The high dynamic capacity allows it to withstand constant stress and vibration.
