Inner Rings IR85X100X35-XL

Inner Rings IR85X100X35-XL

The IR85X100X35-XL is a needle roller bearing inner ring with an 85mm bore and 100mm outer diameter, crafted from sturdy chrome steel. Its 35mm width and precise tolerances ensure a snug fit in demanding setups.
Pre-lubricated for smooth operation, this ring reduces friction and wear in high-load applications. The 1.1mm rounded edges help with easy installation and alignment.
Compatible with INA bearings, it offers a reliable replacement option for industrial use. Ideal for gearboxes, pumps, or machinery where space-saving needle rollers are needed.
Weighing 582g, it balances durability with manageable handling. RoHS compliance guarantees safe use in various environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR85X100X35-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.014mm to -0.027mm
  • Width 35 mm
  • Width Tolerance -0.2mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 582 g
  • Rmin 1.1 mm
Inner Rings IR85X100X35-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of IR85X100X35-XL Bearing
IR85X100X35-XL Bearing is crafted from high-quality chrome steel, ensuring durability and resistance to wear.
Its precise bore diameter of 85 mm with a tight tolerance guarantees a secure fit for various applications.
The needle roller design allows for efficient load distribution, enhancing performance under stress.
With a weight of 582 g, it offers a balance between strength and ease of handling.
How Does IR85X100X35-XL Bearing Reduce Friction?
IR85X100X35-XL Bearing’s needle roller design minimises friction, promoting smooth operation.
The chrome steel construction further enhances its ability to withstand high loads without excessive wear.
Pre-lubricated for immediate use, it ensures optimal performance from the first installation.
Its outer diameter tolerance of -0.014mm to -0.027mm ensures precise alignment, reducing unnecessary friction.
Engineered for Precision: IR85X100X35-XL Bearing
IR85X100X35-XL Bearing is designed for applications requiring exact measurements and reliable performance.
The 35 mm width provides stability, while the chrome steel material offers long-lasting durability.
Its needle roller type ensures efficient load handling, making it suitable for high-stress environments.
With RoHS compliance, it meets stringent environmental and safety standards.
Steel vs Ceramic Bearings: Strengths of IR85X100X35-XL Bearing
IR85X100X35-XL Bearing’s chrome steel construction provides excellent strength and wear resistance.
Unlike ceramic bearings, it offers better impact resistance and is more cost-effective for many applications.
The needle roller design ensures efficient load distribution, enhancing its performance under pressure.
Its pre-lubricated feature ensures smooth operation right from the start.

Application

Essential Roles of IR85X100X35-XL Bearing
IR85X100X35-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The chrome steel construction ensures durability in demanding environments.
In automotive applications, IR85X100X35-XL Bearing fits well in transmission systems, providing smooth operation under heavy loads. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, IR85X100X35-XL Bearing supports precise movements in robotic arms and conveyor systems. The lubricated design helps maintain performance over extended periods.
In household appliances like washing machines, IR85X100X35-XL Bearing offers reliable performance with minimal maintenance. Its compact design is ideal for space-constrained applications.
