Inner Rings IR80X90X35-XL

Inner Rings IR80X90X35-XL

The IR80X90X35-XL is a needle roller bearing inner ring with an 80mm bore and 90mm outer diameter, crafted from sturdy chrome steel. Its 35mm width and precise tolerances ensure a snug fit in demanding applications.
Pre-lubricated for smooth operation, it reduces friction and wear during use. The design includes a 1mm minimum corner radius for easier installation.
This model is compatible with INA bearings, offering flexibility for replacements or upgrades. It suits high-load scenarios like gear pumps or transmission systems where space is limited.
Weighing 355g, it’s a compact yet durable component. Compliant with RoHS standards, it meets environmental and safety requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR80X90X35-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.017mm to -0.004mm
  • Width 35 mm
  • Width Tolerance -0.15mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 355 g
  • Rmin 1 mm
Inner Rings IR80X90X35-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of IR80X90X35-XL Bearing
IR80X90X35-XL Bearing is crafted from chrome steel, offering durability and resistance to wear.
Its needle roller design ensures efficient load distribution, making it suitable for compact spaces.
The precise bore and outer diameter tolerances enhance fit and performance in demanding applications.
With a width of 35 mm, it provides stability while maintaining a lightweight profile at just 355 g.
Lubrication is pre-applied, ensuring smooth operation from the first use.
IR80X90X35-XL Bearing meets RoHS standards, making it an environmentally friendly choice.

Application

Industrial Uses of IR80X90X35-XL Bearing
IR80X90X35-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The chrome steel construction ensures durability in demanding environments.
In automotive applications, IR80X90X35-XL Bearing fits well in transmission systems, providing smooth operation under heavy loads. Its metric dimensions make it a versatile choice for various vehicle models.
For automation equipment, IR80X90X35-XL Bearing supports precise movements in robotic arms and conveyor systems. The lubricated design helps maintain performance over extended periods.
In medical devices, IR80X90X35-XL Bearing offers reliable performance in imaging equipment. Its compact size and high load capacity make it suitable for space-constrained applications.
