Inner Rings IR50X58X40-XL

Inner Rings IR50X58X40-XL

The IR50X58X40-XL is a needle roller bearing inner ring with a 50mm bore and 58mm outer diameter, crafted from sturdy chrome steel. It’s designed for smooth operation and comes pre-lubricated for immediate use.
With a width of 40mm, it fits snugly in compact spaces, while the 0.6mm chamfer ensures easy installation. The bearing meets RoHS standards, making it safe for various industrial applications.
This model is interchangeable with INA bearings, offering a reliable alternative for replacements. Ideal for use in gearboxes, pumps, or other machinery where precision and durability are key.
Weighing just 208g, it’s lightweight yet robust, suitable for high-performance environments. Its simple design makes maintenance straightforward.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR50X58X40-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 58 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 40 mm
  • Width Tolerance -0.12mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 208 g
  • Rmin 0.6 mm
Inner Rings IR50X58X40-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of IR50X58X40-XL Bearing
IR50X58X40-XL Bearing is crafted from chrome steel, offering durability and resistance to wear.
Its precise bore and outer diameter tolerances ensure a perfect fit for needle roller applications.
The lubricated design reduces friction, promoting smooth operation in various conditions.
With a width of 40 mm, it provides stable performance in compact spaces.
IR50X58X40-XL Bearing’s RoHS compliance makes it suitable for environmentally conscious applications.
Its lightweight design at 208 g ensures easy handling without compromising strength.

Application

Essential Roles of IR50X58X40-XL Bearing
IR50X58X40-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The chrome steel construction ensures durability in demanding environments.
In automotive transmissions, IR50X58X40-XL Bearing provides smooth operation, thanks to its precise tolerances and lubrication. It’s a reliable choice for compact spaces where performance matters.
For automation systems, IR50X58X40-XL Bearing supports robotic arms and conveyor belts, offering stability under continuous use. Its metric sizing makes it easy to integrate into various machinery designs.
In medical devices like diagnostic equipment, IR50X58X40-XL Bearing’s consistent performance ensures accurate results. The lubricated design reduces friction, extending the bearing’s lifespan.
