22216 CC KJ W33 Double Row Spherical Roller Bearing

22216 CC KJ W33 Double Row Spherical Roller Bearing

The 22216 CC KJ W33 is a double-row spherical roller bearing with an 80mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 54629 lbf and operates smoothly at speeds up to 6000 RPM.

Its open design and lubrication groove make maintenance straightforward, while the steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where combined loads are frequent.

Weighing 2.1kg, it balances robustness with practicality. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22216 CC KJ W33
  • Brand TFL
  • Interchangeable SKF
  • Size 80 x 140 x 33 mm
  • Bore Dia 80 mm
  • Bore Dia Tolerance +0.03mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.06mm to 0
  • Shoulder Dia Of Inner Ring 94.7 mm
  • Shoulder/Recess Dia Of Outer Ring 124 mm
  • Width Of Lubrication Groove 6 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 54629 lbf
  • Static Radial Load 60698 lbf
  • Max Speed 6000 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 2.1 kg
  • Price （US$） 50.94

Features

Performance Features of 22216 CC KJ W33 Bearing

22216 CC KJ W33 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 54629 lbf, ensuring reliable performance in heavy-duty applications.

The double-row spherical roller design allows for smooth operation even under misalignment conditions.
With a maximum speed of 6000 rpm, it balances durability and efficiency in demanding environments.

22216 CC KJ W33 Bearing’s steel cage maintains roller alignment, reducing wear and extending service life.
The lubrication groove and holes ensure consistent lubrication, minimising maintenance requirements.

Designed for temperatures from -30° to 200°C, 22216 CC KJ W33 Bearing performs well in varied conditions.
Its tapered bore simplifies installation, saving time and effort during setup.

Application

Industrial Uses of 22216 CC KJ W33 Bearing
22216 CC KJ W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction ensures smooth operation even with slight misalignments.

Where Is 22216 CC KJ W33 Bearing Used?
In mining equipment, 22216 CC KJ W33 Bearing provides reliable performance under extreme conditions, thanks to its robust chrome steel construction. The lubrication groove design also extends service life in dusty environments.

Built for Heavy-Duty Use: 22216 CC KJ W33 Bearing
This bearing excels in paper mill machinery, where high speeds and heavy loads are common. Its tapered bore ensures a secure fit, reducing slippage during operation.

Automotive vs Aerospace: Applications of 22216 CC KJ W33 Bearing
In automotive applications, 22216 CC KJ W33 Bearing supports drivetrain components, offering durability under combined loads. For aerospace, its high-temperature tolerance makes it suitable for auxiliary systems.

Essential Roles of 22216 CC KJ W33 Bearing
Wind turbines benefit from 22216 CC KJ W33 Bearing’s ability to handle dynamic loads and misalignment. The steel cage enhances stability, making it a dependable choice for renewable energy systems.
