Inner Rings IR20X24X20-XL

Inner Rings IR20X24X20-XL

The IR20X24X20-XL is a needle roller bearing inner ring with a 20mm bore and 24mm outer diameter, crafted from sturdy chrome steel. Its compact width of 20mm makes it a space-saving choice for tight assemblies.
Pre-lubricated for smooth operation, it’s ready to use straight out of the box. The precise tolerances ensure a snug fit, reducing wear over time.
With a minimal corner radius of 0.3mm, it fits seamlessly into designs where space is limited. RoHS compliant, it meets environmental standards for safe handling.
Ideal for applications like gear pumps or small transmissions, this ring is interchangeable with INA models for easy replacement. Weighing just 21.3g, it’s lightweight yet durable.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number IR20X24X20-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Series IR
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.012mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • Material Chrome Steel
  • Lubrication Lubricated
  • RoHS Compliant
  • Weight 21.3 g
  • Rmin 0.3 mm
Inner Rings IR20X24X20-XL dimension drawing
Download DWG Download PDF

Features

Performance Features of IR20X24X20-XL Bearing
IR20X24X20-XL Bearing is crafted from high-quality chrome steel, offering excellent durability and resistance to wear.
Its precise bore diameter of 20 mm ensures a snug fit, reducing slippage and enhancing performance.
The needle roller design allows for high load capacity in a compact space, making it ideal for tight installations.
With RoHS compliance, IR20X24X20-XL Bearing meets environmental standards while maintaining reliability.

Application

Industrial Uses of IR20X24X20-XL Bearing
IR20X24X20-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads in compact spaces. The chrome steel construction ensures durability even in demanding environments.
In automotive applications, IR20X24X20-XL Bearing fits well in transmission systems, providing smooth operation under high-speed conditions. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, IR20X2420-XL Bearing’s compact design is ideal for robotic arms and precision machinery. The lubricated feature reduces friction, enhancing performance in continuous operation scenarios.
In household appliances like washing machines, IR20X24X20-XL Bearing offers reliable support for rotating components. Its lightweight design contributes to energy efficiency without compromising strength.
