HM262749V Single Cones (Imperial)

HM262749V Single Cones (Imperial)

The HM262749V is a single-row tapered roller bearing cone with a 13.625-inch bore, designed for combined loads. Made from durable chrome steel, it handles dynamic radial loads up to 446,000 lbf and operates in temperatures from -30°C to 110°C.

Its open design allows for easy maintenance, while the steel cage ensures reliable performance. The cone has a width of 3.75 inches and is part of the HM262700 series, interchangeable with Timken bearings.

This bearing is ideal for heavy-duty applications like industrial machinery or large vehicles where combined loads are common. It meets RoHS and REACH standards for safe use.

With standard radial clearance and ABEC-1 rating, it offers a balance of precision and durability. The effective center location of -0.25 inches helps with proper alignment in assemblies.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number HM262749V
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Inch
  • Type Cones
  • Bearing Part Number HM262749V-HM262710
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Series HM262700
  • Bore Dia 13.625"
  • Bore Dia Tolerance +0.001" to 0
  • Cone Width 3.75"
  • Cone Width Tolerance +0.003" to -0.01
  • Cone Backface ToClear Radius 0.25"
  • Cone Frontface Backing Diameter 14.45"
  • Cone Backface Backing Diameter 14.84"
  • Cage Cone Frontface Clearance 0.2"
  • Cage Cone Backface Clearance 0.26"
  • Effective Center Location -0.25"
  • Ring Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 446000 lbf
  • Static Radial Load 845000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 116000 lbf
  • Dynamic Radial Rating(Two Row 1 Million Revolutions)(C1) 776000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 66200 lbf
  • Dynamic Radial Rating(Two Row 90 Million Revolutions)(C90) 201000 lbf
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant

Features

How Does HM262749V Bearing Handle Combined Loads?

HM262749V Bearing is crafted from chrome steel, offering robust resistance to both radial and thrust loads.
Its dynamic radial load capacity reaches 446,000 lbf, making it suitable for heavy-duty applications.

The tapered roller design ensures smooth operation under combined loads, enhancing efficiency.
With a temperature range of -30° to 110°C, HM262749V Bearing performs reliably in various conditions.

The steel cage maintains roller alignment, reducing wear and extending service life.
Its standard radial clearance options provide flexibility for different operational needs.

Application

Industrial Uses of HM262749V Bearing
HM262749V Bearing is commonly used in heavy machinery, such as mining equipment and construction vehicles, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability in tough working conditions.

Where Is HM262749V Bearing Used?
You’ll find HM262749V Bearing in agricultural machinery, supporting components like tractor axles and harvesters. Its inch sizing makes it a good fit for older or custom-built equipment.

Built for Heavy-Duty Use: HM262749V Bearing
HM262749V Bearing excels in industrial gearboxes, providing reliable performance under high radial and thrust loads. The open seal design allows for easy lubrication, extending its service life.

Automotive vs Aerospace: Applications of HM262749V Bearing
In automotive applications, HM262749V Bearing is often used in truck wheel hubs, while in aerospace, it supports landing gear systems. Its high dynamic load capacity makes it versatile across industries.

Essential Roles of HM262749V Bearing
HM262749V Bearing plays a key role in railway applications, particularly in axle boxes where stability under heavy loads is crucial. The steel cage adds extra strength for long-term use.
