Heavy Duty Needle Roller Bearings (Machined) NKI10/16-XL

Heavy Duty Needle Roller Bearings (Machined) NKI10/16-XL

The NKI10/16-XL is a heavy-duty needle roller bearing with a 10mm bore and 22mm outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 2565 lbf and spins at speeds up to 24600 RPM, making it suitable for high-speed applications.
Its open design requires lubrication but allows for easy maintenance, while the steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -20°C to 110°C.
Designed for press-fit mounting, it’s a practical choice for compact spaces. This model is interchangeable with INA bearings, offering flexibility for replacements. Ideal for use in gearboxes, pumps, or industrial machinery where space and load capacity are key concerns.
Weighing just 29.4g, it’s lightweight yet robust. Compliant with RoHS standards, it’s a safe and reliable option for various engineering needs.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NKI10/16-XL
  • Brand TFL
  • Interchangeable brand INA
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Inner Ring Yes
  • Series With Inner Ring
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Steel
  • Cage Material Steel
  • Roller Material Steel
  • Dynamic Radial Load 2565 lbf
  • Static Radial Load 2588 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 24600 rpm
  • Weight 29.4 g
Heavy Duty Needle Roller Bearings (Machined) NKI10/16-XL dimension drawing
Download DWG Download PDF

Features

How Does NKI10/16-XL Bearing Handle High-Speed Applications?
NKI10/16-XL Bearing is built with steel rings and rollers, designed to handle high radial loads efficiently.
Its dynamic radial load capacity of 2565 lbf ensures reliable performance in demanding conditions.
The steel cage maintains roller alignment, reducing friction and wear during high-speed operation.
With a maximum speed of 24,600 rpm, it offers both durability and precision for industrial applications.

Application

Industrial Uses of NKI10/16-XL Bearing
NKI10/16-XL Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The press-fit mounting ensures a secure connection, ideal for heavy machinery.
Where Is NKI10/16-XL Bearing Used?
In automotive applications, NKI10/16-XL Bearing supports components like transmission systems, providing reliable performance under stress. Its compact size fits well in tight spaces without compromising durability.
Built for Heavy-Duty Use: NKI10/16-XL Bearing
This bearing excels in construction equipment, where its steel construction withstands harsh conditions. The open design allows for easy lubrication, extending its service life.
Automotive vs Industrial: Applications of NKI10/16-XL Bearing
While NKI10/16-XL Bearing is popular in vehicle drivetrains, it also shines in industrial presses. Its high-speed capability and radial load capacity make it versatile across sectors.
Perfect Fit for Automation: NKI10/16-XL Bearing
In robotic arms, NKI10/16-XL Bearing ensures smooth movement with minimal friction. The steel rollers and cage provide the necessary strength for repetitive tasks.
