Flanged Deep Groove Ball Bearings W 623 R-2RS1

Flanged Deep Groove Ball Bearings W 623 R-2RS1

The W 623 R-2RS1 is a compact flanged deep groove ball bearing, measuring just 3mm by 10mm by 4mm, with a stainless steel construction for durability. It handles radial loads up to 80 lbf and spins smoothly at speeds up to 40,000 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance for long-term use. The flange adds stability, helping the bearing stay securely in place during operation.

This model works well in temperatures from -30°C to 120°C and is interchangeable with SKF bearings. Ideal for small machinery, medical devices, or precision instruments where space is limited.

Weighing only 0.0017kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 623 R-2RS1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Bore Dia 3 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 10 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.12mm to 0
  • Flange Outer Dia 11.5 mm
  • Flange Thickness 1 mm
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 80 lbf
  • Static Radial Load 25 lbf
  • Max Speed 40000 rpm
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.0017 kg
  • Price（$） 1.5
Flanged Deep Groove Ball Bearings W 623 R-2RS1 dimension drawing
Download DWG Download PDF

Features

How Does W 623 R-2RS1 Bearing Reduce Friction?

W 623 R-2RS1 Bearing features a sealed design with stainless steel components, ensuring smooth operation and reduced friction.
Its single-row construction and grease lubrication help maintain efficiency even at high speeds up to 40,000 rpm.
The flanged outer diameter provides secure mounting, preventing misalignment and further minimising wear.
With a dynamic radial load capacity of 80 lbf, it offers reliable performance in compact applications.

Application

Where Is W 623 R-2RS1 Bearing Used?
W 623 R-2RS1 Bearing is commonly found in small electric motors, such as those used in cooling fans or miniature appliances. Its compact size and sealed design make it ideal for spaces where dust or moisture might be an issue.

In robotics, W 623 R-2RS1 Bearing provides smooth rotation for joints and small actuators, thanks to its stainless steel construction. The flange adds extra stability, ensuring precise alignment in tight assemblies.

For medical devices like dental tools or diagnostic equipment, W 623 R-2RS1 Bearing offers reliable performance with minimal maintenance. The grease lubrication ensures quiet operation, which is essential in sensitive environments.

You’ll also spot W 623 R-2RS1 Bearing in consumer electronics, such as printers or handheld gadgets. Its lightweight design and durability make it a go-to for manufacturers aiming for long-lasting performance.
