FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1007-M1-F1-J20AA-C3

FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1007-M1-F1-J20AA-C3

The FAG NU1007-M1-F1-J20AA-C3 is a current-insulated cylindrical roller bearing with a 35mm bore and 62mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating, offering insulation up to 1000V.

With a dynamic load rating of 29kN and a static load rating of 26kN, it handles heavy radial loads smoothly. The brass cage ensures durability, while the C3 clearance allows for thermal expansion.

The bearing’s insulating properties make it ideal for electric motors or generators where stray currents are a concern. It operates efficiently at speeds up to 9700r/min.

Weighing just 0.18kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU1007-M1-F1-J20AA-C3
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 35.0 mm
  • Outside Diameter 62.0 mm
  • Width 14.0 mm
  • Net Weight 0.18 kg
  • Basic Dynamic Load Rating 29 kN
  • Basic Static Load Rating 26 kN
  • Reference Speed 9700r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material M - Brass Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NU1007-M1-F1-J20AA-C3 dimension drawing
Download DWG Download PDF

Features

How Is NU1007-M1-F1-J20AA-C3 Bearing Engineered for Reliability?

NU1007-M1-F1-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical arcing, ensuring reliable performance in electrically charged environments.

The brass cage maintains proper roller alignment, reducing friction and wear.
With a basic dynamic load rating of 29 kN, it handles heavy radial loads efficiently.

NU1007-M1-F1-J20AA-C3 Bearing operates smoothly at speeds up to 9,700 rpm.
Its C3 radial internal clearance allows for thermal expansion in high-speed applications.

The ceramic coating offers high electrical resistance, even in damp conditions.
This makes NU1007-M1-F1-J20AA-C3 Bearing suitable for use in motors and generators.

Application

Industrial Uses of NU1007-M1-F1-J20AA-C3 Bearing
NU1007-M1-F1-J20AA-C3 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent electrical damage. The ceramic coating on the outer ring ensures reliable performance in environments with stray currents.

In automation systems, NU1007-M1-F1-J20AA-C3 Bearing supports high-speed operations in robotic arms and conveyor belts. Its brass cage design provides stability and reduces friction during prolonged use.

For wind turbine applications, NU1007-M1-F1-J20AA-C3 Bearing handles radial loads efficiently while resisting electrical arcing. The C3 clearance allows for thermal expansion, making it suitable for variable operating conditions.

What Makes NU1007-M1-F1-J20AA-C3 Bearing a Preferred Choice?
NU1007-M1-F1-J20AA-C3 Bearing is ideal for CNC machinery, where precision and electrical insulation are critical. Its high dynamic load rating ensures durability in demanding industrial settings.

In railway systems, NU1007-M1-F1-J20AA-C3 Bearing is used in traction motors to withstand vibrations and electrical interference. The ceramic coating adds an extra layer of protection against current leakage.

For medical imaging devices, NU1007-M1-F1-J20AA-C3 Bearing offers smooth operation and electrical safety. The damp resistance feature ensures consistent performance even in humid environments.
