Electrically Insulated Single Row Cylindrical Roller Bearings NU 219 ECM/C3VL0241

Electrically Insulated Single Row Cylindrical Roller Bearings NU 219 ECM/C3VL0241

This electrically insulated cylindrical roller bearing has a compact build, measuring 95mm in bore, 170mm outside, and 32mm wide. It’s made with a robust design to handle substantial radial loads.

The bearing supports dynamic loads up to 530 kN and static loads up to 540 kN, operating smoothly at speeds up to 3400 RPM. Its C3 internal clearance accommodates thermal expansion during use.

A key feature is the outer ring’s insulating coating, which prevents electrical damage by resisting voltages from 1000 to 3000 VDC. The machined brass cage adds durability and helps maintain performance.

Suitable for electric motors or generators where stray currents are a concern, it’s also RoHS and REACH compliant. Weighing 2.84kg, it offers reliable protection in demanding industrial settings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU 219 ECM/C3VL0241
  • Product Category Electrically Insulated Single Row Cylindrical Roller Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers TFL
  • Bore Diameter 95 mm
  • Outside Diameter 170 mm
  • Width 32 mm
  • Net Weight 2.84 kg
  • Basic Dynamic Load Rating 530.0 kN
  • Basic Static Load Rating 540.0 kN
  • Reference Speed 3400.0r/min
  • Breakdown Voltage (DC) 1000 VDC to 3000 VDC
  • Layer Thic kNess 500 µm
  • Electrical Resistance Min. 50MΩ
  • Cage Material Machined brass
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
Electrically Insulated Single Row Cylindrical Roller Bearings NU 219 ECM/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Does NU 219 ECM/C3VL0241 Bearing Prevent Electrical Damage?

NU 219 ECM/C3VL0241 Bearing features an outer ring insulation coating that withstands voltages from 1000 to 3000 VDC.
This electrical protection prevents current passage through the bearing, eliminating damage from stray currents.
With a minimum electrical resistance of 50MΩ, it ensures reliable operation in electrically active environments.
The machined brass cage maintains proper roller alignment while contributing to the bearing’s electrical insulation properties.

Application

How Does NU 219 ECM/C3VL0241 Bearing Improve Performance?
NU 219 ECM/C3VL0241 Bearing works well in industrial equipment like large motors and conveyor drives, where its electrical insulation prevents damage from stray currents.
The cylindrical roller design handles heavy radial loads smoothly, making it suitable for continuous operation in demanding environments.

In automotive electric powertrains, NU 219 ECM/C3VL0241 Bearing supports components like traction motors, where its insulation coating protects against electrical erosion.
With C3 clearance and brass cage, it maintains stable performance under varying thermal conditions common in vehicle applications.

For medical imaging devices, NU 219 ECM/C3VL0241 Bearing’s electrical resistance ensures reliable operation in sensitive equipment where electrical interference must be minimized.
The consistent performance helps maintain precision in diagnostic machinery that requires uninterrupted service.

Within automation systems, NU 219 ECM/C3VL0241 Bearing finds use in robotic arms and precision positioning equipment, where its insulation properties prevent electrical arcing.
The bearing’s construction allows for smooth movement in automated production lines that require both electrical safety and mechanical reliability.

In consumer appliances like industrial-grade washing machines, NU 219 ECM/C3VL0241 Bearing provides durable support for rotating drums while protecting against electrical issues.
The bearing’s design makes it practical for household equipment that needs long service life with minimal maintenance.
