Electrically Insulated Single Row Cylindrical Roller Bearings NU 1013 ECP/C3VL0241

Electrically Insulated Single Row Cylindrical Roller Bearings NU 1013 ECP/C3VL0241

This electrically insulated cylindrical roller bearing measures 65mm by 100mm by 18mm, with a robust outer ring coating for protection.
It handles dynamic loads up to 80.9 kN and operates smoothly at speeds reaching 5600 RPM.
The nylon cage reduces friction and noise, while the C3 internal clearance accommodates thermal expansion.
Ideal for electric motors or generators where electrical currents are present, preventing damage from stray currents.
With a breakdown voltage from 1000 to 3000 VDC, it ensures reliable performance in demanding environments.
Compliant with RoHS and REACH standards, it’s a safe choice for various industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU 1013 ECP/C3VL0241
  • Product Category Electrically Insulated Single Row Cylindrical Roller Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers TFL
  • Bore Diameter 65 mm
  • Outside Diameter 100 mm
  • Width 18 mm
  • Net Weight 0.45 kg
  • Basic Dynamic Load Rating 80.9 kN
  • Basic Static Load Rating 104.0 kN
  • Reference Speed 5600.0r/min
  • Breakdown Voltage (DC) 1000 VDC to 3000 VDC
  • Layer Thic kNess 500 µm
  • Electrical Resistance Min. 50MΩ
  • Cage Material Nylon
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
Electrically Insulated Single Row Cylindrical Roller Bearings NU 1013 ECP/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Does NU 1013 ECP/C3VL0241 Bearing Prevent Electrical Damage?

NU 1013 ECP/C3VL0241 Bearing features an outer ring insulation coating that withstands up to 3000 VDC, protecting against electrical currents.
This coating provides a minimum electrical resistance of 50MΩ, effectively preventing electrical erosion in motor applications.
The C3 radial internal clearance accommodates thermal expansion during operation, maintaining consistent performance.
With a basic dynamic load rating of 80.9 kN, NU 1013 ECP/C3VL0241 Bearing handles substantial radial loads while ensuring electrical safety.

Application

How Does NU 1013 ECP/C3VL0241 Bearing Improve Performance?
NU 1013 ECP/C3VL0241 Bearing works well in industrial equipment like conveyor systems and large fans where electrical currents might cause damage. Its special insulation coating prevents electrical arcing, which helps extend the machinery’s service life.
In automotive electric motors, NU 1013 ECP/C3VL0241 Bearing handles high speeds while protecting components from stray currents. The nylon cage contributes to smooth operation, making it suitable for various driving conditions.
For medical imaging devices, NU 1013 ECP/C3HL0241 Bearing’s electrical insulation ensures accurate readings by preventing current interference. This reliability is important in diagnostic equipment where precision matters.

Where Is NU 1013 ECP/C3VL0241 Bearing Used?
You’ll often find NU 1013 ECP/C3VL0241 Bearing in automation equipment like robotic arms and assembly line systems. The electrical insulation protects sensitive electronics from damage caused by induced currents.
In consumer appliances such as washing machines and power tools, NU 1013 ECP/C3VL0241 Bearing provides dependable performance while preventing electrical issues. Its C3 clearance allows for thermal expansion during continuous operation.
The bearing’s construction makes it practical for industrial fans and pumps where both electrical protection and high-speed capability are needed. This combination supports consistent performance in demanding environments.

Industrial Uses of NU 1013 ECP/C3VL0241 Bearing
NU 1013 ECP/C3VL0241 Bearing serves well in machine tools and industrial drives where electrical insulation is necessary. The coating withstands voltages up to 3000 VDC, protecting against current passage.
In electric vehicle components, NU 1013 ECP/C3VL0241 Bearing supports high rotational speeds while preventing electrical damage. This makes it useful in traction motors and charging systems.
For laboratory equipment and measurement devices, NU 1013 ECP/C3VL0241 Bearing maintains accuracy by eliminating electrical interference. The nylon cage helps reduce noise during precise operations.
