FAG Current-Insulated Single Row Cylindrical Roller Bearing NU212-E-XL-M1-F1-J20AA-C3

FAG Current-Insulated Single Row Cylindrical Roller Bearing NU212-E-XL-M1-F1-J20AA-C3

The FAG NU212-E-XL-M1-F1-J20AA-C3 is a current-insulated cylindrical roller bearing with a 60mm bore and 110mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating (J20AA) for insulation, with a breakdown voltage of up to 1000V.

This bearing handles dynamic loads up to 112 kN and static loads up to 103 kN, making it suitable for high-performance applications. The brass cage ensures durability, while the C3 radial clearance allows for thermal expansion.

With a reference speed of 5300 rpm, it’s ideal for electric motors or generators where electrical insulation is crucial. The coating maintains high resistance (50MΩ dry, 10MΩ damp) for reliable operation.

Weighing 0.9kg, it’s a robust yet compact solution. Compliant with RoHS and REACH standards, it’s a safe choice for industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU212-E-XL-M1-F1-J20AA-C3
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 60.0 mm
  • Outside Diameter 110.0 mm
  • Width 22.0 mm
  • Net Weight 0.9 kg
  • Basic Dynamic Load Rating 112 kN
  • Basic Static Load Rating 103 kN
  • Reference Speed 5300r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material M - Brass Cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NU212-E-XL-M1-F1-J20AA-C3 dimension drawing
Download DWG Download PDF

Features

How Does NU212-E-XL-M1-F1-J20AA-C3 Bearing Resist Electrical Currents?

NU212-E-XL-M1-F1-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
The coating offers a breakdown voltage of up to 1000V, making it suitable for applications with electrical interference.

Its brass cage ensures smooth operation and durability, even under high dynamic loads of 112 kN.
The bearing maintains stable performance with a reference speed of 5300r/min.

With a layer thickness of 200 um, NU212-E-XL-M1-F1-J20AA-C3 Bearing provides reliable electrical resistance in both dry and damp conditions.
This design reduces the risk of electrical damage, extending the bearing’s service life.

The C3 radial internal clearance allows for thermal expansion, ensuring consistent performance in varying temperatures.
Its robust construction makes it a dependable choice for industrial applications.

Application

Industrial Uses of NU212-E-XL-M1-F1-J20AA-C3 Bearing
NU212-E-XL-M1-F1-J20AA-C3 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The brass cage ensures smooth operation even under high rotational speeds.

What Makes NU212-E-XL-M1-F1-J20AA-C3 Bearing a Preferred Choice?
In wind turbines, NU212-E-XL-M1-F1-J20AA-C3 Bearing handles heavy radial loads while its ceramic coating protects against stray currents. The C3 clearance allows for thermal expansion in demanding environments.

Perfect Fit for Automation: NU212-E-XL-M1-F1-J20AA-C3 Bearing
NU212-E-XL-M1-F1-J20AA-C3 Bearing works well in robotic arms, offering reliable performance with minimal maintenance. Its high dynamic load rating makes it suitable for repetitive motion applications.

Medical vs Industrial: Where NU212-E-XL-M1-F1-J20AA-C3 Bearing Excels
NU212-E-XL-M1-F1-J20AA-C3 Bearing is ideal for industrial pumps due to its damp-resistant insulation. In medical imaging devices, its precision ensures quiet and vibration-free operation.
