Electrically Insulated Ball Bearings 6322/C3VL0241

Electrically Insulated Ball Bearings 6322/C3VL0241

The 6322/C3VL0241 is an electrically insulated ball bearing with a 110mm bore and 240mm outer diameter, designed to prevent electrical currents from passing through. Its robust construction handles dynamic loads up to 216 kN and spins smoothly at speeds up to 6000 RPM.

The outer ring features a special insulation coating, offering a breakdown voltage of 1000-3000V and electrical resistance of 50-200 MΩ. This makes it ideal for use in electric motors or generators where stray currents can cause damage.

With a C3 radial clearance and sheet metal cage, it ensures reliable performance under varying temperatures and loads. Compliant with RoHS and REACH standards, it’s a safe choice for industrial applications.

Weighing 9.32kg, this bearing balances durability and practicality, suitable for heavy-duty machinery requiring electrical insulation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6322/C3VL0241
  • Product Category Electrically Insulated Ball Bearings
  • Coating Suffix VL0241
  • Insulating Coating Types Insulation coating on outer ring
  • Manufacturers TFL
  • Bore Diameter 110.0 mm
  • Outside Diameter 240.0 mm
  • Width 50.0 mm
  • Net Weight 9.32kg
  • Basic Dynamic Load Rating 216.0 kN
  • Basic Static Load Rating 180.0 kN
  • Reference Speed 6000.0 r/min
  • Breakdown Voltage (DC) 1000 ~3000 V
  • Layer Thickness 100~500 µm
  • Electrical Resistance 50~200 MΩ
  • Cage Material Sheet metal
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
Electrically Insulated Ball Bearings 6322/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is 6322/C3VL0241 Bearing Engineered for Reliability?

6322/C3VL0241 Bearing features an insulating coating on the outer ring, preventing electrical damage in high-voltage environments.

Its breakdown voltage ranges from 1000 to 3000 V, ensuring safe operation in electrically charged applications.

The bearing’s dynamic load rating of 216 kN allows it to handle heavy loads with ease.

With a reference speed of 6000 r/min, it offers both durability and high-speed performance.

Application

Industrial Uses of 6322/C3VL0241 Bearing
The 6322/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical currents from damaging the bearing. This makes it ideal for industries relying on high-voltage equipment.

In wind turbines, 6322/C3VL0241 Bearing handles both radial and axial loads while resisting electrical erosion. Its C3 clearance ensures reliable performance even under varying thermal conditions.

For railway applications, 6322/C3VL0241 Bearing’s durability and insulation properties protect against stray currents in electrified tracks. The sheet metal cage adds strength without compromising electrical resistance.

Where Is 6322/C3VL0241 Bearing Used?
You’ll often find 6322/C3VL0241 Bearing in industrial pumps, where its insulation coating prevents corrosion from electrical discharge. The high dynamic load rating also suits heavy-duty pumping systems.

In manufacturing automation, 6322/C3VL0241 Bearing supports robotic arms and conveyor systems, ensuring smooth operation without electrical interference. Its wide temperature range adapts to diverse factory environments.

Built for Heavy-Duty Use: 6322/C3VL0241 Bearing
The 6322/C3VL0241 Bearing excels in mining equipment, where its robust design withstands harsh conditions. The insulation coating adds an extra layer of protection against electrical damage.

For HVAC systems, 6322/C3VL0241 Bearing’s reliable performance and electrical insulation make it a smart choice for large fans and blowers. Its high reference speed ensures efficient airflow control.

Automotive vs Aerospace: Applications of 6322/C3VL0241 Bearing
In electric vehicles, 6322/C3VL0241 Bearing prevents current leakage in traction motors, enhancing safety and longevity. The metric sizing fits standard EV motor designs.

For aerospace applications, 6322/C3VL0241 Bearing’s lightweight construction and insulation properties suit auxiliary power units. Its compliance with ROHS and REACH standards meets strict industry regulations.
