Drawn Cup Needle Roller Bearings SCE1010-PP

Drawn Cup Needle Roller Bearings SCE1010-PP

The SCE1010-PP is a drawn cup needle roller bearing with a 0.625″ bore and 0.8125″ outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 1821 lbf and spins smoothly at speeds up to 16000 RPM.
Its double-seal design keeps contaminants out while maintaining lubrication, ideal for dusty or demanding environments. The press-fit shaft mount ensures a secure installation without slipping.
This bearing is interchangeable with INA models, making replacements straightforward. Perfect for applications like automotive components or small machinery where space is tight but durability is key.
Operating in temperatures from -20°C to 110°C, it’s versatile for various conditions. RoHS compliant for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE1010-PP
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.625"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 0.8125"
  • Outer Dia Tolerance Not Rated
  • Width 0.625"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Double Seal
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 1821 lbf
  • Static Radial Load 2698 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 16000 rpm
  • Weight 10 g
Drawn Cup Needle Roller Bearings SCE1010-PP dimension drawing
Download DWG Download PDF

Features

How Does SCE1010-PP Bearing Reduce Friction?
SCE1010-PP Bearing features a double-sealed design, keeping contaminants out and lubrication in for smoother operation.
Its steel construction ensures durability while handling dynamic radial loads up to 1821 lbf.
The needle roller design minimises friction, making it ideal for high-speed applications up to 16,000 rpm.
With a press-fit shaft mount, SCE1010-PP Bearing offers easy installation and reliable performance.
Designed for radial loads, it operates efficiently in temperatures ranging from -20 to 110°C.
The steel cage maintains roller alignment, reducing wear and extending service life.

Application

Common Applications of SCE1010-PP Bearing
SCE1010-PP Bearing works well in industrial settings, especially in compact machinery where space is limited. Its double-seal design helps keep contaminants out, extending the bearing’s lifespan.
In automotive applications, SCE1010-PP Bearing is often used in gearboxes and steering systems. The press-fit mounting ensures a secure installation, even under high radial loads.
For automation equipment, SCE1010-PP Bearing provides smooth operation in robotic arms and conveyor systems. Its steel construction offers durability, making it suitable for continuous use.
In household appliances like washing machines, SCE1010-PP Bearing handles radial loads efficiently. The inch sizing makes it compatible with many standard designs.
