23152 CAC/W33VE552E Double Row Spherical Roller Bearing

23152 CAC/W33VE552E Double Row Spherical Roller Bearing

The 23152 CAC/W33VE552E is a double-row spherical roller bearing with a 260mm bore and 440mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 577309 lbf and operates smoothly at speeds up to 1400 RPM.

Its brass cage and spherical rollers ensure durability, while the open design allows for easy lubrication. The bearing performs well in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 91kg, it’s robust and built to last. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23152 CAC/W33VE552E
  • Brand TFL
  • Interchangeable SKF
  • Size 260 x 440 x 144 mm
  • Bore Dia 260 mm
  • Bore Dia Tolerance -0.035mm to 0
  • Outer Dia 440 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 144 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 314 mm
  • Shoulder/Recess Dia Of Outer Ring 380 mm
  • Width Of Lubrication Groove 16.7 mm
  • Diameter Of Lubrication Hole 9 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 577309 lbf
  • Static Radial Load 843034 lbf
  • Max Speed 1400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 91 kg
  • Price （US$） US$1,763.13

Features

Performance Features of 23152 CAC/W33VE552E Bearing

23152 CAC/W33VE552E Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 577309 lbf, making it suitable for heavy-duty industrial applications.

The brass cage ensures smooth roller alignment, reducing friction and enhancing durability.
With a maximum speed of 1400 rpm, it maintains stable performance under demanding conditions.

23152 CAC/W33VE552E Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its robust construction and precise tolerances ensure reliable operation in varied environments.

Application

Industrial Uses of 23152 CAC/W33VE552E Bearing
23152 CAC/W33VE552E Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently.
The brass cage and chrome steel construction ensure durability even in high-vibration environments, making it a reliable choice for mining and construction equipment.

Where Is 23152 CAC/W33VE552E Bearing Used?
In wind turbines, 23152 CAC/W33VE552E Bearing supports the main shaft, providing stability under varying wind conditions.
Its high dynamic load capacity and lubrication groove design help maintain performance in these demanding applications.

Built for Heavy-Duty Use: 23152 CAC/W33VE552E Bearing
23152 CAC/W33VE552E Bearing excels in paper mill machinery, where its spherical roller design compensates for misalignment.
The wide temperature range and robust construction make it suitable for continuous operation in harsh industrial settings.

Automotive vs Aerospace: Applications of 23152 CAC/W33VE552E Bearing
In large commercial vehicles, 23152 CAC/W33VE552E Bearing is often found in wheel hubs and transmissions, offering long service life.
While less common in aerospace, its high load capacity could support ground support equipment or heavy-duty aircraft components.

Practical Applications of 23152 CAC/W33VE552E Bearing
23152 CAC/W33VE552E Bearing is ideal for steel plants, where it’s used in rolling mills to withstand extreme loads and temperatures.
The metric sizing and interchangeable design with SKF bearings make it a versatile option for global industrial applications.
