Drawn Cup Needle Roller Bearings BCE66-P

Drawn Cup Needle Roller Bearings BCE66-P

The BCE66-P is a drawn cup needle roller bearing with a 0.375″ bore and 0.5625″ outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 652 lbf and spins efficiently at speeds up to 25000 RPM.
Its single-seal design keeps contaminants out while the press-fit mounting ensures a secure fit. The closed-end construction adds durability, making it suitable for high-speed applications.
This bearing requires lubrication for optimal performance and operates well in temperatures from -20°C to 110°C. It’s interchangeable with INA bearings, offering a practical replacement option.
Ideal for use in compact spaces like automotive components or small machinery, where radial load support is needed. Compliant with RoHS standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number BCE66-P
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.375"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 0.5625"
  • Outer Dia Tolerance Not Rated
  • Width 0.375"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Single Seal
  • Series Closed End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 652 lbf
  • Static Radial Load 607 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 25000 rpm
  • Weight 5 g
Drawn Cup Needle Roller Bearings BCE66-P dimension drawing
Download DWG Download PDF

Features

How Does BCE66-P Bearing Handle High-Speed Applications?
BCE66-P Bearing features a steel construction, providing robust performance under radial loads.
Its dynamic radial load capacity of 652 lbf ensures reliable operation in high-speed environments.
The single-seal design helps retain lubrication, reducing friction and wear during operation.
With a maximum speed of 25,000 rpm, it is well-suited for demanding industrial applications.
BCE66-P Bearing’s press-fit mounting simplifies installation, saving time and effort.
Its temperature range of -20 to 110°C allows for versatile use in various conditions.

Application

Industrial Uses of BCE66-P Bearing
BCE66-P Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed, such as conveyor systems and printing presses. Its single seal design helps keep contaminants out while maintaining smooth operation.
Where Is BCE66-P Bearing Used?
You’ll often find BCE66-P Bearing in automotive applications like gearboxes and steering systems, where its press-fit design ensures a secure hold. The steel construction provides durability, even under high-speed conditions.
Perfect Fit for Automation: BCE66-P Bearing
In robotics and automation, BCE66-P Bearing works well in robotic arms and small actuators due to its compact size and reliable performance. The inch measurements make it a good fit for machinery using imperial standards.
Medical vs Industrial: Where BCE66-P Bearing Excels
For medical devices like dental tools, BCE66-P Bearing offers precision and quiet operation. In industrial settings, it handles heavy loads in equipment like textile machines, proving its versatility.
Essential Roles of BCE66-P Bearing
BCE66-P Bearing is a go-to choice for household appliances like power tools, where its high-speed capability and durability shine. The steel cage ensures long-lasting performance, even with frequent use.
