Double Row Cylindrical Roller Thrust Bearings assembly K 89415 M

Double Row Cylindrical Roller Thrust Bearings assembly K 89415 M

The K 89415 M is a double-row cylindrical roller thrust bearing measuring 75mm by 160mm by 17mm, built with chrome steel rollers for strength. It handles heavy radial loads up to 90000 lbf and spins smoothly at speeds up to 1900 RPM.

Its machined brass cage ensures durability and reduces friction, while the two-row design provides extra stability under thrust loads. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy machinery or industrial equipment where high radial and thrust loads are common.

Weighing 1.78kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K 89415 M
  • Size 75 mm x 160 mm x 17 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 75 mm
  • Bore Dia Tolerance +0.06mm to +0.25mm
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.52mm to -1.15mm
  • Diameter Roller 17 mm
  • Raceway Diameter (min.) Roller And Cage Thrust Assembly 82 mm
  • Raceway Diameter (max.) Roller And Cage Thrust Assembly 156 mm
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 90000 lbf
  • Static Radial Load 344250 lbf
  • Max Speed 1900 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 1.78 kg
  • Shaft Washer WS 89415
  • Housing Washer GS 89415

Features

How Does K 89415 M Bearing Handle Heavy Loads?

K 89415 M Bearing features a double-row cylindrical roller design, ideal for handling high thrust loads with precision.
Its chrome steel rollers and machined brass cage ensure durability and smooth operation under heavy radial loads.
With a dynamic radial load capacity of 90,000 lbf, it performs reliably in demanding industrial applications.
The bearing’s temperature range of -30° to 110°C makes it suitable for various operating conditions.

Why Choose K 89415 M Bearing for Precision Tasks?

K 89415 M Bearing’s precise dimensions (75 mm x 160 mm x 17 mm) ensure accurate fit and performance.
The machined brass cage maintains roller alignment, reducing friction and enhancing efficiency.
Its static radial load capacity of 344,250 lbf provides stability in high-load scenarios.
The bearing’s compatibility with SKF models adds versatility for replacements and upgrades.

Built for Reliability: K 89415 M Bearing

K 89415 M Bearing is engineered for long-term performance, thanks to its robust chrome steel rollers.
The double-row design distributes loads evenly, minimising wear and extending service life.
With a maximum speed of 1,900 rpm, it balances speed and durability in industrial settings.
Its RoHS and REACH compliance ensures it meets environmental and safety standards.

Steel vs Ceramic Bearings: Strengths of K 89415 M Bearing

K 89415 M Bearing’s chrome steel rollers offer superior strength and resistance to heavy loads.
The machined brass cage provides excellent heat dissipation and reduces operational noise.
Its high static radial load capacity (344,250 lbf) makes it a reliable choice for industrial machinery.
The bearing’s metric dimensions ensure seamless integration with standard equipment.

Application

Industrial Uses of K 89415 M Bearing
K 89415 M Bearing is commonly used in heavy machinery, such as hydraulic presses and large gearboxes, where its double-row design handles significant thrust loads. The machined brass cage ensures smooth operation even under high stress.

Where Is K 89415 M Bearing Used?
In automotive applications, K 89415 M Bearing supports components like transmission systems, providing reliable performance under constant load. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: K 89415 M Bearing
K 89415 M Bearing excels in industrial settings, such as mining equipment, where durability and load capacity are critical. The chrome steel rollers enhance its longevity in harsh environments.

Automotive vs Aerospace: Applications of K 89415 M Bearing
In automotive systems, K 89415 M Bearing is ideal for transmissions, while in aerospace, it supports auxiliary power units. Its high dynamic load rating ensures reliability in both fields.

Essential Roles of K 89415 M Bearing
K 89415 M Bearing is vital in wind turbines, where it handles axial and radial loads efficiently. The brass cage reduces friction, making it suitable for continuous operation.
